Direct procurement2008 Model

Sell your Chevalier K3 Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: K3 Year
Year: 2008
Category: CNC Milling Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier K3 Year Specifications

Table Size: 10" x 50"
Longitudinal Travel: 30"
Cross Travel: 15 3/8"
Vertical Travel (knee): 15"
Table T-Slots Quantity: 3
Table T-Slots Size: 0.63"
Maximum Workpiece Weight: 946 Lbs.
Vertical Spindle Motor: 3 HP
Spindle Speeds: 50-4,500 RPM
Spindle Taper: R8
Spindle Nose to Table: 1 5/8"-16 1/2"
Spindle Centerline to Column Surface: 4"-25 5/8"
Quill Travel: 5"
Automatic Vertical Feeds: 0.0015", 0.003", 0.006"
Head Swivel R&L: 90 Deg.
Head Swivel F&B: 45 Deg.
Overarm Travel: 21 5/8"
Overarm Swivel: 360 Deg.
Weights (Approx.): 3,350 Lbs.
Floor Space: 79" x 101 1/4" x 84 5/8"
Electrics: 230 Volts, 3 Phase

Do you have a Chevalier K3 Year to sell?

We are actively seeking a 2008 Chevalier K3 Vertical Milling Machine equipped with Acu-Rite G2 Control. This machine features a spacious 10" x 50" table, making it ideal for a variety of milling tasks. With a longitudinal travel of 30" and cross travel of 15 3/8", it offers excellent versatility in handling different workpieces. The vertical travel of the knee is 15", allowing for significant adjustment when working with various materials. The machine can support a maximum workpiece weight of 946 lbs, ensuring it can handle substantial components with ease.

Powered by a robust 3 HP vertical spindle motor, the Chevalier K3 operates at spindle speeds ranging from 50 to 4,500 RPM, providing the flexibility needed for both roughing and finishing operations. The spindle taper is R8, which is widely recognized and compatible with a vast array of tooling options. The spindle nose to table height ranges from 1 5/8" to 16 1/2", allowing for precise positioning and setup of workpieces. With automatic vertical feeds adjustable at 0.0015", 0.003", and 0.006", you can achieve consistent and repeatable cuts. The head swivels a full 90 degrees right and left, as well as 45 degrees forward and backward, enhancing the machine's capability for angled milling operations.

The overarm travel reaches 21 5/8", and it can swivel a complete 360 degrees, providing even more flexibility. This machine has an approximate weight of 3,350 lbs and occupies a floor space of 79" x 101 1/4" x 84 5/8". It operates on 230 volts, 3-phase power, making it suitable for most industrial settings. If you are looking to sell or upgrade your Chevalier K3 Vertical Milling Machine, contact Superior Machine Tools today to get the best value for your equipment!
