Direct procurement2000 Model

Sell your Chevalier EVS today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: EVS
Year: 2000
Category: CNC Milling Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier EVS Specifications

Table working surface: 9" x 48"
Number of t-slots: 3
Longitudinal range: 32-1/2"
Cross range: 12"
Vertical, knee range: 16"
Quill range: 5"
Maximum distance, spindle nose to top of table: 18.5"
Minimum distance, spindle nose to top of table: 2.5"
Maximum distance, centerline of spindle to face of column: 18.75"
Minimum distance, centerline of spindle to face of column: 6.75"
Ram travel: 12"
Head tilt, left & right: 90 degrees
Head tilt, front to rear: 45 degrees
Turret rotation: 360 degrees
Power quill feeds: .0015, .003, .006 I.P.R.
Spindle speeds: 60-4,200 R.P.M
Spindle taper: R-8
Maximum collet capacity: 3/4"

Do you have a Chevalier EVS to sell?

We are actively seeking a 2000 CHEVALIER EVS Vertical Milling Machine to purchase. This robust CNC milling machine features a table working surface of 9" x 48", making it ideal for various machining tasks. With three t-slots for secure workpiece clamping and a longitudinal range of 32-1/2", it provides ample space for your projects. The cross range of 12" and a vertical knee range of 16" allow for versatile operation, while the quill range of 5" enhances its capability for precision work. The CHEVALIER EVS is designed with maximum flexibility in mind.

It has a maximum spindle nose to table distance of 18.5" and a minimum distance of 2.5", accommodating a range of tooling and setups. Additionally, the machine's spindle centerline to face of column distances, ranging from 6.75" to 18.75", ensure that users can achieve the desired positioning with ease. The ram travel of 12" adds to its adaptability, allowing for adjustments as needed. Operators will appreciate the head tilt features, offering left and right tilts of 90 degrees and front to rear tilts of 45 degrees, as well as turret rotation of 360 degrees for complete versatility in machining angles. The power quill feeds are adjustable, providing options for feeds at .0015, .003, and .006 inches per revolution.

With spindle speeds ranging from 60 to 4,200 RPM and an R-8 spindle taper, this machine is ready to tackle a wide variety of materials. Its maximum collet capacity of 3/4" ensures that you can work with different sizes of tooling. If you have a CHEVALIER EVS Vertical Milling Machine from 2000 that you're looking to sell, we invite you to contact us today. At Superior Machine Tools, we specialize in buying used CNC machines, and we can offer you a competitive price for your equipment.
