Direct procurement2007 Model

Sell your Okamoto OMG-1220OPB today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Okamoto
Model: OMG-1220OPB
CNC Control: CNC (Fanuc Oi-TB CNC Control) CNC (Fanuc Oi-TB CNC Control)
Year: 2007
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okamoto OMG-1220OPB Specifications

Swing: 12.6" 320.04 mm
Centers: 20" 508 mm
Grinding Wheel Dia.: 16" 406.4 mm
Wheel Power: 5 hp 3.7 kW
Wheel Speed: 1,845 RPM 1,845 RPM
Control: CNC (Fanuc Oi-TB CNC Control) CNC (Fanuc Oi-TB CNC Control)
Dimensions: 143″ x 76″ x 67″ High
Weight: 7700 lbs Approx.
Max Grinding Diameter: 12.0″
Max Grinding Length: 19.68″
Max Weight Between Centers: 330 lbs
Distance Between Centers: 20.0″
Grinding Wheel: Speed: 1845 RPM wheel Size: 16″ x 2″ x 5″
Grinding Wheel Spindle Motor: 5 HP
Wheelhead: Total Stroke (X-Axis): 11.8″
Automatic Infeed: 0.00001” – 0.004″
Minimum Increment: 0.00001”
Continuous Feedrate: 160 IPM
Wheelhead Rapid Retract: 1.5″
Grind Feed Override: 0 – 200%
Workhead: Center Taper: MT-4
Speed: 10 – 500 RPM
Motor: 1 HP
Table: Maximum Table Travel: 34″
Swivel Angle: 0 to .10°
Traverse Speed: 0 – 400 IPM
Rapid Feedrate: 400 IPM
Feedrate Override: 0 – 200%
Tailstock: Tailstock Quill Stroke: 1.2″
Tailstock Taper: MT-4
Power Source: AC 200 V Three Phase 60 Hz
Power Requirement: 20 kva
Overall Dimensions: 143″ x 76″ x 67″ High.

Do you have a Okamoto OMG-1220OPB to sell?

We are actively seeking a 2007 Okamoto OGM 12-20PB CNC cylindrical grinder. This high-performance machine is ideal for precision grinding applications and is equipped with a robust 5 HP grinding wheel spindle motor. With a maximum grinding diameter of 12.0 inches and a grinding length of 19.68 inches, it is capable of handling a variety of machining tasks with ease. The machine features a swing of 12.6 inches and a distance between centers of 20 inches, making it versatile for different workpieces. The OGM 12-20PB operates at a wheel speed of 1,845 RPM, ensuring efficient material removal and a smooth finish.

The CNC control system utilizes a Fanuc Oi-TB CNC control, providing precision and repeatability for complex grinding operations. With an automatic infeed range of 0.00001" to 0.004" and a continuous feedrate of 160 IPM, this grinder can be tailored to meet specific production needs. In terms of design, the machine's overall dimensions are 143" x 76" x 67" high, and it weighs approximately 7,700 lbs, offering stability during operation. The workhead features a center taper of MT-4 and operates at speeds between 10 to 500 RPM, while the tailstock has a quill stroke of 1.2 inches and also features an MT-4 taper. The table allows for a maximum travel of 34 inches and a swivel angle of 0 to 10°, which adds to the machine's versatility.

If you are looking to sell your used CNC machines, especially the 2007 Okamoto OGM 12-20PB, we invite you to reach out to us at Superior Machine Tools. We offer competitive prices and a straightforward selling process. Let us help you maximize the value of your equipment today!
