Direct procurement2017 Model

Sell your Okamoto OGM1220NCAGIII today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Okamoto
Model: OGM1220NCAGIII
Year: 2017
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okamoto OGM1220NCAGIII Specifications

Swing Over Table: 12.6"
Distance Between Centers: 20"
Max. Diameter to be Ground: 12"
Max. Weight Between Centers: 330 Lbs
Grinding Wheel Size: 20" x 4" x 8"
Grinding Wheel Speed: 500 ~ 2,400 RPM
Grinding Wheel Motor: 10 HP
Wheelhead Total Stroke: 11.8"
Wheelhead Swivel Angle: +/- 30°
Wheelhead Auto Infeed: 0.00001" ~ 0.004"
Wheelhead Min. Increment: 0.00001"
Wheelhead Rapid Feedrate: 157 IPM
Table Max. Table Travel: 31"
Table Swivel Angle: 0 - 8.5°
Table Max. Traverse: 394 IPM
Table Min. Increment: 0.00001"
Table Rapid Feedrate: 94 IPM
Workhead Center: MT#5
Workhead Swivel Angle: +30 / -90°
Workhead Speed: 500 RPM
Tailstock Center: MT#4
Tailstock Stroke: 1.2"

Do you have a Okamoto OGM1220NCAGIII to sell?

We are actively seeking a 2017 Okamoto OGM1220NCAGIII, a top-tier cylindrical grinder known for its precision and efficiency. This model features a swing over table of 12.6 inches and a distance between centers of 20 inches, making it ideal for grinding workpieces with a maximum diameter of 12 inches and a weight capacity of 330 lbs. The OGM1220NCAGIII is designed with a robust 10 HP grinding wheel motor that powers a grinding wheel size of 20 inches by 4 inches by 8 inches, allowing for high-performance grinding at speeds ranging from 500 to 2,400 RPM. With its advanced wheelhead design, the OGM1220NCAGIII boasts a total stroke of 11.8 inches and a swivel angle of +/- 30°, ensuring versatile grinding capabilities.

The wheelhead auto infeed can be finely adjusted between 0.00001 inches and 0.004 inches, with a minimum increment of 0.00001 inches, enabling precise control over grinding operations. The rapid feed rate for the wheelhead is an impressive 157 IPM, while the table allows a maximum travel of 31 inches with a traverse speed of 394 IPM. The workhead center is equipped with an MT#5 taper, featuring a swivel angle of +30 to -90° and a workhead speed of 500 RPM. Additionally, the tailstock center comes with an MT#4 taper and a tailstock stroke of 1.2 inches, providing added flexibility for various grinding tasks.

If you have a 2017 Okamoto OGM1220NCAGIII to sell, we invite you to reach out to us. At Superior Machine Tools, we specialize in purchasing high-quality used CNC machines, and we can offer you a competitive price for your equipment. Don't miss the opportunity to sell your machine to a trusted buyer in the industry!
