Direct procurement2013 Model

Sell your Okamoto ACC-16.32ST Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Okamoto
Model: ACC-16.32ST Year
Year: 2013
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okamoto ACC-16.32ST Year Specifications

Serial Number: 88618
Capacity: 16" x 32"
Maximum Wheel Diameter: 12"
Hydraulic Table Travel: 10 to 82 FPM
Longitudinal Table Travel: 37.5"
Cross Travel: 17.5"
Table Load Capacity: 1500 lbs
Table Cross Feeds (Intermittent): 0.02 to 0.8 IPM
Table Cross Feed (Continuous): 8 to 40 IPM
Automatic Down Feed (Variable): 0.0002 to 0.0015 IPM
Spindle Elevation Speeds: 19 IPM
Walker Chuck Size: 16" x 32" x 3"
Hydraulic Over the Wheel Dressor: Yes
3-Axis Power with Incremental Down Feed: Yes
1-Axis Vertical DRO: Mini Wizzard
Hydraulic Motor: 3 HP
Spindle Motor: 5 HP.

Do you have a Okamoto ACC-16.32ST Year to sell?

We are actively seeking a 2013 Okamoto ACC-16.32ST surface grinder. This robust machine features a capacity of 16" x 32" and a maximum clearance of 21.5" under the new wheel, making it an excellent choice for precision grinding applications. The ACC-16.32ST is equipped with a hydraulic table that offers variable travel speeds from 10 to 82 feet per minute, allowing for efficient handling of various workpieces. With a longitudinal table travel of 37.5" and a cross travel of 17.5", this grinder can accommodate a wide range of parts, while its impressive table load capacity of 1500 lbs ensures stability during operation.

The machine also boasts table cross feeds with intermittent settings ranging from 0.02 to 0.8 inches per minute and continuous feeds from 8 to 40 inches per minute, providing flexibility for different grinding tasks. Additionally, the automatic down feed is variable, allowing for precise adjustments between 0.0002 to 0.0015 inches per minute. Featuring a 12" x 1-1/2" x 5" grinding wheel and a Walker chuck measuring 16" x 32" x 3", the Okamoto ACC-16.32ST is designed for high performance. It includes a hydraulic over-the-wheel dresser and utilizes 3-axis power with incremental down feed, ensuring accuracy and efficiency in every grind.

The hydraulic motor operates at 3 horsepower, complemented by a 5 horsepower spindle motor for powerful grinding capabilities. If you have a 2013 Okamoto ACC-16.32ST surface grinder that you are looking to sell, we invite you to contact us. Our team at Superior Machine Tools is ready to provide you with a competitive offer and assist you in making the sale process seamless.
