Direct procurement1989 Model

Sell your Okamoto 1632N Width/Cross today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Okamoto
Model: 1632N Width/Cross
Year: 1989
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okamoto 1632N Width/Cross Specifications

Machine Serial No.: 8542
Machine Model No.: 1632N
Maximum Grinding: 16" Wide x 32" Long
Maximum Vertical Clearance: 14"
Diameter Wheel (50 Hz): 20.6"
Diameter Wheel (60 Hz): 21.6"
Table Load Capacity: 1,550 Lbs.
Maximum Table Travel (Manual): 17.3" x 37.4"
Table Working Surface: 15.7" x 37.4"
Longitudinal Movement of Table Hydraulic Feed: 10' to 83' per Minute
Cross Movement of Saddle Hydraulic Intermittent Feed: 0.02" to 0.8"
Hydraulic Continuous Feed: 8" to 40" per Minute
Hand Feed per Revolution: 0.25"
Vertical Movement of Wheelhead Automatic Feed per Table Stroke: 0.0002" to 0.0015"
Automatic Feed per Saddle Reversal: 0.0002 to 0.0015"
Hand Feed per Revolution: 0.05"
Manual Incremental Feed: 0.0001" to 0.0015"
Rapid Feed (50/60 Hz): 16"/19" per Minute
Grinding Wheel Diameter (50/60 Hz): 14"/12"
Grinding Wheel Width: 1-1/2"
Grinding Wheel Bore: 5"
Spindle Motor: 5 HP, Wired for 3 Phase, 60 Cycle, 220 Volts
Hydraulic Pump Motor: 2 HP
Vertical Rapid Feed Motor: 1/2 HP
Machine Dimensions: 96" LR x 80" FB x 88" High x Approx. 7,780 Lbs.
Coolant Tank Dimensions: 40" LR x 30" FB x 36" High.

Do you have a Okamoto 1632N Width/Cross to sell?

We are actively seeking a 1989 Okamoto 1632N Surface Grinder, a fully automatic saddle type machine that excels in precision grinding. This impressive model features a table working surface of 16" x 32" and a grinding width capacity of 16", making it ideal for a variety of grinding tasks. With a grinding length capacity of 32", it offers substantial versatility for your machining needs. The height under the 12" grinding wheel is 21.6", allowing for efficient operation and easy accessibility. This machine has a robust table load capacity of 1550 LBS, ensuring it can handle heavy workpieces with ease.

The Okamoto 1632N is powered by a 5 HP grinding wheel spindle motor that operates at 1800 RPM, providing the necessary power for high-speed grinding applications. It is equipped with a grinding wheel diameter of 12" and a width of 1.5", with a hole diameter of 1.25". The table longitudinal feeds range from 1 to 83 FPM, while the table cross in-feeds can adjust from 0.02 to 0.8 IPR, allowing for precise control over the grinding process. Additionally, the spindle vertical feeds offer a fine adjustment capability of 0.0001 to 0.0015 IPR. Weighing approximately 7900 LBS, this machine is a solid investment for any manufacturing environment.

If you are considering selling your 1989 Okamoto 1632N Surface Grinder, we would love to hear from you. At Superior Machine Tools, we specialize in purchasing used CNC machines, and we guarantee you a fair price for your equipment. Contact us today to discuss your machine and get a quote!
