Direct procurement2004 Model

Sell your Doosan V550M today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Doosan
Model: V550M
Year: 2004
Category: CNC Vertical Turning Centers
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Doosan V550M Specifications

Chuck Size: 15" 3-Jaw
Maximum Swing: 30.7"
Max Turning Diameter: 19.68"
Max Turning Length: 24.20"
Spindle Height Surface From Floor: 41.73"
Hole Through Spindle: 4.33"
Spindle Speeds: 20 - 2,000 RPM
Spindle Torque: 509 Ft-Lbs.
Max Spindle Orientation: C-Axis, (.001 Degree)
C-Axis Max Speed: 55.5 RPM
Turret Travels (X/Z): 14.57" x 24.02"
Rapid Traverse (X/Z): 787 IPM
Turret Capacity: 12 Stations (VDI 50)
Turret Index Time: 0.7 Second 1 Tool / 1.08 Sec 6 Tools
Max Number of Live Tools: 12 Live Tool
Max Speed: 4,000 RPM
Rotary Tool Drive: 9.4 HP
Main Spindle Drive: 50 / 40 HP.

Do you have a Doosan V550M to sell?

We are actively seeking a 2004 Doosan V550M CNC Vertical Turning Center with Live Milling. This exceptional machine features a 15" 3-jaw chuck, allowing for efficient handling of various workpieces. With a maximum swing of 30.7" and a max turning diameter of 19.68", the V550M is perfect for a wide range of applications. Its impressive max turning length of 24.20" enables it to accommodate larger parts, making it an ideal addition to your machining capabilities. The spindle of the V550M is designed for versatility, offering speeds ranging from 20 to 2,000 RPM and delivering a robust torque of 509 Ft-Lbs.

This ensures that you can tackle demanding projects with ease. Additionally, the C-axis capability allows for precise spindle orientation with a max speed of 55.5 RPM, providing superior control over your machining processes. With turret travels of 14.57" in the X-axis and 24.02" in the Z-axis, along with rapid traverse rates of 787 IPM, the V550M ensures high productivity and efficiency. The turret capacity of 12 stations (VDI 50) allows for quick tool changes, with an impressive turret index time of just 0.7 seconds for one tool and 1.08 seconds for six tools. Equipped with a maximum of 12 live tools, the V550M can achieve speeds up to 4,000 RPM, supported by a 9.4 HP rotary tool drive.

The main spindle drive provides a robust performance with 50/40 HP, making it a powerhouse for your machining needs. If you have a 2004 Doosan V550M CNC Vertical Turning Center with Live Milling that you are looking to sell, we at Superior Machine Tools are ready to make you a competitive offer. Contact us today to discuss the details and get the best value for your used machinery!
