DMG MORI ntx 2000szm 1500 fanuc 31ib5 25 9 swing 2 kitagawa chucks non thru (2014)

Direct procurement2014 Model

Sell your DMG MORI ntx 2000szm 1500 fanuc 31ib5 25 9 swing 2 kitagawa chucks non thru today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: DMG MORI
Model: ntx 2000szm 1500 fanuc 31ib5 25 9 swing 2 kitagawa chucks non thru
CNC Control: Fanuc 31iB5
Year: 2014
Category: CNC Turning Centers
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

DMG MORI ntx 2000szm 1500 fanuc 31ib5 25 9 swing 2 kitagawa chucks non thru Specifications

Maximum Workpiece Swing Diameter: 660 mm (25.9 in.)
Swing Over Cross Slide - Standard: 660 mm (25.9 in.)
Swing Over Cross Slide - Turret 2: 300 mm (11.8 in.)
Maximum Turning Diameter - Standard: 610 mm (24.0 in.)
Maximum Turning Diameter - B-axis: 660 mm (25.9 in.)
Maximum Turning Diameter - Turret 2: 274 mm (10.7 in.)
Maximum Turning Length: 1,540 mm (60.6 in.)
Travel X-axis: 495 mm (19.5 in.)
Travel Y-axis: 125 mm (4.9 in.)
Travel Z-axis: 1,560 mm (61.4 in.)
Travel B-axis: 120
Travel X2-axis: 160 mm (6.3 in.)
Travel Z2-axis: 1,402 mm (55.2 in.)
Maximum Spindle Speed - Spindle 1: 5,000 min-1
Maximum Spindle Speed - Spindle 2: 5,000 min-1
Through-Spindle Hole Diameter - Spindle 1: 73 mm (2.9 in.)
Through-Spindle Hole Diameter - Spindle 2: 73 mm (2.9 in.)
Spindle 1 Torque: 230/178/159 Nm (169.6/131.3/117.3 ftlbf)
Spindle 2 Torque: 230/178/159 Nm (169.6/131.3/117.3 ftlbf)
Tool Spindle Speed: 12,000 min-1
Inner Diameter of Rotary Tool Spindle Bearing: 70 mm (2.7 in.)
Tool Storage Capacity: 38 tools
Maximum Tool Diameter: 125 mm (4.9 in.)
Maximum Tool Length: 300 mm (11.8 in.)
Maximum Tool Mass: 10 kg (22 lb.)
Turret 2 Tool Stations: 10
Turret 2 Indexing Time: 0.19 sec
Rapid Traverse Rate - X/Y/Z/X2/Z2/A-axis: 40,000 mm/min (1,574.8 ipm) / 30,000 mm/min (1,181.1 ipm) / 38,000 mm/min (1,496.1 ipm) / 30,000 mm/min (1,181.1 ipm)
Spindle 1 Drive Motor: 22/18.5 kW (30/24.7 HP)
Spindle 2 Drive Motor: 22/18.5 kW (30/24.7 HP)
Tool Spindle Drive Motor: 18.5/11 kW (24.7/15 HP)
Electrical Power Supply: 79.9 kVA
Compressed Air Supply: 0.5 MPa (72.5 psi), 650 L/min (171.6 gpm)
Coolant Tank Capacity: 675 L (178.2 gal.)
Machine Height: 2,621 mm (103.2 in.)
Floor Space: 4,080 x 2,980 mm (160.6 x 117.3 in.)
Mass of Machine with 38 Tools: 15,270 kg (33,594 lb.)
Mass of Machine with 76 Tools: 15,780 kg (34,716 lb.)
CNC Control: Fanuc 31iB5
Milling Spindle Speed: 12,000 RPM
Equipped With: Lower Turret with Live Tooling, Coolant System, Chip Conveyor, (2) Kitagawa N08 Chucks (Non Thru)

Do you have a DMG MORI ntx 2000szm 1500 fanuc 31ib5 25 9 swing 2 kitagawa chucks non thru to sell?

We are actively seeking a 2014 DMG Mori NTX-2000SZM/1500 equipped with a Fanuc 31iB5 control system. This high-performance CNC turning center offers a maximum workpiece swing diameter of 25.9 inches, making it ideal for a variety of machining applications. With its advanced live tooling capabilities, this machine features two Kitagawa chucks that are non-thru, providing versatility for complex part geometries. The NTX-2000SZM/1500 delivers a maximum turning diameter of 25.9 inches and a turning length of 60.6 inches, allowing for substantial workpiece handling.

Its dual spindles both reach a maximum spindle speed of 5,000 RPM, ensuring efficient material removal and improved productivity. The machine's X-axis travel of 19.5 inches and Z-axis travel of 61.4 inches allow for precise positioning, while the rapid traverse rates of up to 40,000 mm/min ensure swift movements between operations. Additionally, the tool spindle speed of 12,000 RPM and a tool storage capacity of 38 tools enable quick tool changes and enhanced operational efficiency. We appreciate the compact design with a machine height of 103.2 inches and a floor space requirement of 160.6 x 117.3 inches, making it suitable for various shop layouts.

If you have a 2014 DMG Mori NTX-2000SZM/1500 for sale, we would love to hear from you. Contact us today to discuss your machine and receive a competitive offer for your equipment.
