Direct procurement

Sell your Chevalier FSG-3A1224H Width/Cross today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: FSG-3A1224H Width/Cross
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-3A1224H Width/Cross Specifications

Table Size: 12" x 24"
X Travel: 25.6"
Y Travel: 14.17"
Z Travel: 21"
RPM: 1750
Max Table Load: 924 lbs
Wheel Size: 14" x 2" x 5"
Bore Main Motor HP: 5
Hydraulic Motor: 2
Equipped with: Magnetic Chuck, Coolant Unit
Approximate Overall Dimensions: 80" x 72" x 80"
Approximate Overall Weight: 4,630 lbs
Machine Type: Grinders, Surface

Do you have a Chevalier FSG-3A1224H Width/Cross to sell?

We are actively seeking a Chevalier FSG-3A1224H surface grinding machine. This reliable equipment features a table working surface of 12" x 24" and is equipped with a powerful 5 HP grinding wheel spindle motor, making it an excellent choice for precision grinding applications. The maximum grinding width capacity is 12", while the maximum grinding length capacity reaches 24", allowing for versatility in your machining tasks. With a height spindle centerline to table of 24.75", this machine can accommodate various workpiece sizes.

The standard grinding wheel diameter is 14", and it has a width of 2", with a hole diameter of 5" to ensure compatibility with a wide range of grinding wheels. The table offers both hydraulic and manual longitudinal travel options, with a hydraulic travel of 25.37" and a manual travel of 27.5". For cross travel, the automatic range is 14.17", and the manual option is 14.5", providing flexibility in operation. The machine's table longitudinal feeds range from 16 to 82 feet per minute, while the cross in-feeds range from 0.125 to 2 inches per revolution, allowing for precise control over grinding processes.

The automatic spindle vertical feeds can be adjusted from 0.0001 to 0.002 inches per revolution, ensuring optimal grinding results. With a power rapid vertical traverse of 13 inches per minute, efficiency is maximized during operation. The overall dimensions require a floor space of 106" x 66", with an overall height of 82", and it weighs approximately 4630 pounds. If you have a Chevalier FSG-3A1224H that you are looking to sell, contact us today to get a competitive offer and turn your surplus machinery into cash!
