Direct procurement1994 Model

Sell your Chevalier FSG-3A1020 Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: FSG-3A1020 Year
Year: 1994
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-3A1020 Year Specifications

Nominal Grinding Capacity: 10" x 20"
Max. Longitudinal Table Travel, Hydraulic: 22-7/8"
Max. Longitudinal Table Travel, Manual: 24-1/8"
Max. Crossfeed Travel, Automatic: 11-7/16"
Max. Crossfeed Travel, Manual: 11-1/4"
Distance from Spindle Center to Table: 21-1/2"
Variable Table Speed, Hydraulic: 16' to 82' FPM
Automatic Crossfeed Increment: 0.02" to 0.4"
Power Rapid Traverse (Cross): 48" IPM
Crossfeed Handwheel, Per Graduation: 0.001" per revolution
Automatic Incremental Downfeed: 0.0001" to 0.002"
Auto Downfeed Dial Per Graduation: 0.0005" per revolution
Microfeed: 0.0001"
Rapid Traverse Rate: 13" IPM
Spindle Motor: 5 HP
Standard Grinding Wheel: 12" Dia. x 1-1/4" x 1" B
Approx. Weight: 3,306 lbs.
Approx. Dimensions: 85" x 48" x 65"H
Grinding Wheel: 12"
Chuck: 10" x 20" "Walker-Hagou" Made in the Netherlands Electro-Magnetic Chuck
Spindle: Super-Precision Direct Drive Spindle
Voltage: Wired for 60/575 volts, transformer for 230 or 460 volts available for $675
Features: Fully programmable microprocessor auto-cycle control with digital display, sparkout cycle with automatic wheelhead retraction, power rapid wheelhead positioning, hydraulic table traverse, electronic cross-vertical feeds, micro-downfeed (.0001" grad.), Heidenhain 2-axis digital readout display, over-the-wheel wheel dresser, coolant system with paper filtration, external hydraulic system, auto lube system
Additional: Brand new spindle installed, original paint, excellent condition
Machine Location: Harrison, NJ Warehouse.

Do you have a Chevalier FSG-3A1020 Year to sell?

We are actively seeking a 1994 Chevalier FSG-3A1020 precision surface grinder. This robust machine boasts a nominal grinding capacity of 10" x 20" and is equipped with a 12" diameter grinding wheel, making it ideal for precision grinding tasks. The FSG-3A1020 features a hydraulic longitudinal table travel of 22-7/8" and a manual travel capability of 24-1/8", allowing for versatile operation. Its automatic crossfeed travel reaches 11-7/16", while the manual option allows for 11-1/4" of travel, providing operators with flexibility and ease of use.

The machine is designed with a super-precision direct drive spindle powered by a 5 HP motor, ensuring reliable performance and high-quality results. The variable table speed ranges from 16 to 82 feet per minute, and the automatic incremental downfeed can be finely adjusted from 0.0001" to 0.002", allowing for precise material removal. The fully programmable microprocessor auto-cycle control, complete with a digital display, enhances operational efficiency and accuracy. Additionally, the FSG-3A1020 is equipped with an electromagnetic chuck measuring 10" x 20", which is essential for securely holding workpieces during grinding operations.

It also includes features like a hydraulic table traverse, electronic cross-vertical feeds, and a coolant system with paper filtration, making it a well-rounded choice for any machine shop. With an approximate weight of 3,306 lbs and dimensions of 85" x 48" x 65"H, this machine is both sturdy and compact. Located in our Harrison, NJ warehouse, this Chevalier FSG-3A1020 is in excellent condition with a brand new spindle installed and original paint. If you're looking to sell your used CNC machines, particularly this precision surface grinder, we invite you to contact us today for a competitive offer!
