Direct procurement1993 Model

Sell your Chevalier FSG-3A1020 Width/Cross today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: FSG-3A1020 Width/Cross
Year: 1993
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-3A1020 Width/Cross Specifications

Nominal Grinding Capacity: 10" x 20"
Max. Longitudinal Table Travel, Hydraulic: 22 7/8"
Max. Longitudinal Table Travel, Manual: 24 3/8"
Max. Cross Feed Travel, Automatic: 11 7/16"
Max. Cross Feed Travel, Manual: 11 3/4"
Distance from Spindle Center to Table: 21 1/2"
Variable Table Speed, Hydraulic: 16 - 82 FPM
Automatic Cross Feed Increment: 0.02" - 0.4"
Power Rapid Traverse, Cross: 48 IPM
Cross Feed Handwheel per Graduation: 0.001" Per Revolution: 0.02"
Automatic Incremental Down Feed: 0.0001" - 0.002"
Auto Down Feed Dial per Graduation: 0.0005" Per Revolution: 0.1"
Micro Feed: 0.0001"
Rapid Traverse Rate: 13 IPM
Standard Grinding Wheel: 12" Diameter x 1 1/4" x 3"
Spindle Motor: 3 HP / 460v / 3ph
Dimensions: 85" x 48" x 65" H
Weight: approx. 3,310 lbs.
Standard Features: Fully Programmable Microprocessor Auto-Cycle Control with Digital Display, Automatic Incremental Down Feed (Plunge & Surface), Spark Out Cycle with Automatic Wheel Head Retraction at Completion of Grind Cycle, Power Rapid Wheel Head Positioning, Hydraulic Table Traverse, Electronic Cross & Vertical Feeds, Micro-Down Feed (.0001" Graduation)
Equipment Included: "Sokki" High-Accuracy 'Made in Japan' 2-Axis Digital Read Out Display; Reads to 0.00005" Resolution, 10" x 20" O.S. Walker "LBP" Fine-Division Electro-Magnetic Chuck with Variable Hold Neutrofier Control on the Machine Control Console, Coolant System with Paper Filtration, Work Light, External Hydraulic System, Auto Lube System, 12" Grinding Wheel, 3 HP Super-Precision Direct Drive Spindle.

Do you have a Chevalier FSG-3A1020 Width/Cross to sell?

We are actively seeking a 1993 Chevalier FSG-3A1020 surface grinder to purchase. This reliable CNC grinding machine boasts a 10" x 20" Walker magnetic chuck and is designed for precision grinding tasks. With a robust 6 HP motor and a hydraulic table type, the FSG-3A1020 is perfect for handling various machining operations with ease. The incremental downfeed feature ensures consistent results, making it an excellent choice for both small and large-scale projects. The machine offers impressive longitudinal travel of 20", allowing for substantial workspace while grinding.

The grinding width of 10" is ideal for a variety of applications, and the maximum height from spindle to table is 21-1/2", providing flexibility for different workpiece sizes. Additionally, the FSG-3A1020 is equipped with a coolant system that includes a paper filter, ensuring that your operations remain clean and efficient. Another great feature is the wheel dresser, which enhances the grinding process by maintaining the wheel's shape and sharpness. The auto lube system further ensures that the machine remains in excellent condition, requiring minimal maintenance. With dimensions of 76" LR x 72" FB x 75" H and an estimated weight of 3500 lbs, this machine is robust and built to last.

We are committed to providing fair offers for used CNC machines, and we recognize the value that the Chevalier FSG-3A1020 can bring to our operations. If you have a 1993 Chevalier FSG-3A1020 surface grinder that you are looking to sell, we invite you to reach out to us. Let's discuss how we can make this a seamless transaction for you!
