Direct procurement1999 Model

Sell your Chevalier FSG-2A1224H Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: FSG-2A1224H Year
Year: 1999
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-2A1224H Year Specifications

Table size: 12" x 24"
Max. Distance from Table to Spindle: 24 3/4"
Magnetic Chuck Size: 24" x 12"
Longitudinal Movement: Max. Travel (hydraulic): 25 5/8"
Max. Travel (manual): 27 1/2"
Table Speed: 16 - 82 fpm
Cross Transverse Travel: Rapid travel: approx. 56 ipm
Automatic transverse increment: 0.04" - 0.5"
Max. Automatic transverse travel: 14 1/8"
Max. Manual transverse travel: 14 1/2"
Handwheel per revolution: 0.2"
Handwheel per graduation: 0.001"
Wheelhead Vertical Infeed: Automatic infeed: 0.0001" - 0.0002"
Handwheel per revolution: 0.1"
Handwheel per graduation: 0.0005"
Rapid Travel: approx. 13 ipm
Micro feed per revolution: 0.01"
Micro feed per graduation: 0.0001"
Grinding Wheel: 14" Diameter x 2" Width x 5" Bore
Grinding Spindle: 5 hp, 1,750 rpm @ 60 hz, 1,450 rpm @ 50 hz
Hydraulic Drive: 2 hp
Motor: 10 hp / 230 / 460 v / 3 ph (Pre-Wired: 230 v)
Overall Dimensions: 78" L x 73" W x 84" H
Overall Weight: approx. 4,630 lbs.
New Replacement Cost: $28,500.00 (3-Axis Model)

Do you have a Chevalier FSG-2A1224H Year to sell?

We are actively seeking a 1999 Chevalier FSG-2A1224H, a high-performance 2-axis semi-automatic surface grinder that boasts an impressive array of specifications. Designed for precision and efficiency, this model features a table size of 12" x 24" and a maximum distance from the table to the spindle of 24 3/4". The magnetic chuck size measures 24" x 12", providing ample space for various workpieces. With a longitudinal movement that allows for a maximum hydraulic travel of 25 5/8" and a manual travel of 27 1/2", this grinder is built to accommodate a range of grinding tasks.

The table speed ranges from 16 to 82 feet per minute, ensuring effective grinding operations. For added versatility, the cross transverse travel includes rapid travel of approximately 56 inches per minute, and an automatic transverse increment adjustable from 0.04" to 0.5", with a maximum automatic transverse travel of 14 1/8". The grinder's handwheel offers precise control, with a per revolution adjustment of 0.2" and graduation of 0.001". Equipped with a grinding wheel of 14" diameter, 2" width, and a 5" bore, the FSG-2A1224H features a grinding spindle with 5 horsepower, operating at 1,750 rpm at 60 Hz and 1,450 rpm at 50 Hz.

The hydraulic drive contributes an additional 2 hp, while the overall motor power is 10 hp, compatible with both 230 and 460 volts. With overall dimensions of 78" L x 73" W x 84" H and weighing approximately 4,630 lbs, this machine is robust and reliable. If you have a Chevalier FSG-2A1224H that you wish to sell, we invite you to contact Superior Machine Tools. We specialize in purchasing used CNC machines and can offer you a competitive price for your equipment.
