Make: Chevalier
Model: FSG-1640ADII Year
Year: 2001
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-1640ADII Year Specifications

Table Size: 15-3/4" x 9-5/8"
Max. Grinding Capacity: 16" x 40"
Distance from Spindle Center to Table: 24-3/8"
Max. Longitudinal Table Travel, Hydraulic: 41-5/16"
Max. Longitudinal Table Travel, Manual: 43-1/4"
Variable Table Speed, Hydraulic: 16' to 82' FPM
Max. Crossfeed Travel, Automatic: 16"
Max. Crossfeed Travel, Manual: 18"
Cross Rapid Travel: 12' FPM
Automatic Crossfeed Increment: 1/8" to 1-1/4"
Handwheel per Rev.: 0.25"
Handwheel per Graduation: 0.0025"
Microfeed per Rev.: 0.005"
Microfeed per Grad.: 0.00005"
Automatic Incremental Downfeed: 0.000050" to .002"
Vertical Rapid Traverse Rate: 8" IPM
Spindle Motor: 5 HP
Standard Grinding Wheel: 14"Dia. x 2"W x 5"B
Spindle Speed: 1,750 RPM
Approx. Weight: 9,240 lbs
Approx. Dimensions: 120" x 68" x 76"H
Approx. Dims. Required for Ops.: 158" x 68" x 76"H
Chuck Size: 15-3/4" x 9-3/8"
Electro-Magnetic Chuck Model: KET-40100K
Power: 5 HP/60/575 Volt
Spindle Motor Transformer: Provided, wired for various voltages.

Do you have a Chevalier FSG-1640ADII Year to sell?

We are actively seeking a 2001 Chevalier FSG-1640ADII surface grinder to enhance our inventory of quality used CNC machines. This machine is renowned for its efficiency and precision in surface grinding applications. Featuring a maximum grinding capacity of 16" x 40", it is equipped with a powerful 5 HP spindle motor that operates at a spindle speed of 1,750 RPM. The FSG-1640ADII is designed with a programmable microprocessor that allows for automatic incremental downfeed, providing exceptional control over the grinding process.

The table size measures 15-3/4" x 9-5/8", and it boasts a maximum longitudinal table travel of 41-5/16" when operated hydraulically, or 43-1/4" manually. The variable table speed ranges from 16 to 82 feet per minute, ensuring adaptability to various grinding needs. Additionally, the machine features an electromagnetic chuck, model KET-40100K, with a size of 15-3/4" x 9-3/8", delivering reliable workholding capabilities. With a vertical rapid traverse rate of 8 IPM and an automatic crossfeed increment adjustable from 1/8" to 1-1/4", this grinder is designed for both precision and productivity.

Weighing approximately 9,240 lbs and requiring a footprint of 158" x 68" x 76" for operation, the Chevalier FSG-1640ADII is a robust addition to any machining environment. If you are looking to sell your used Chevalier FSG-1640ADII surface grinder, we invite you to contact us today. Our team at Superior Machine Tools is dedicated to providing you with a seamless selling experience and competitive offers for your machinery.
