Make: Chevalier
Model: FSG-1224AD Year
Year: 2005
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier FSG-1224AD Year Specifications

Table Working Surface: 11.75 in x 12.625 in
Grinding Width Capacity, Max: 12 in
Grinding Length Capacity, Max: 24 in
Height Spindle Center to Table, Max: 24-3/4 in
Grinding Wheel Diameter, Standard: 14 in
Grinding Wheel Width, Standard: 2 in
Grinding Wheel Hole Diameter, Standard: 5 in
Table Longitudinal Travel, Hydraulic: 25.625 in
Table Longitudinal Travel, Manual: 27.5 in
Table Speed: 16 - 82 FPM
Table Cross Travel, Hydraulic: 13.75 in
Table Cross Travel, Manual: 14.125 in
Rapid Traverse: 12.5 FPM
Table Cross In-Feeds: 0.125 - 2 IPR
Microfeed (Per Graduation): 0.00005 in
Microfeed (Per Revolution): 0.005 in
Automatic Infeed: 0.00005 in - 0.003 in
Rapid Traverse: 0 - 20 IPM
Grinding Wheel Spindle Motor: 5 HP
Weight: 4630 LBS
Voltage: 230/460/3/60
Equipped With: Chip Conveyor.

Do you have a Chevalier FSG-1224AD Year to sell?

We are actively seeking a 2005 Chevalier FSG-1224AD Surface Grinder. This robust CNC grinding machine is designed to deliver precision and reliability in surface grinding applications. With a table working surface of 11.75 inches by 12.625 inches, this model boasts a maximum grinding width capacity of 12 inches and a maximum grinding length capacity of 24 inches. The spindle center to table height reaches an impressive 24-3/4 inches, providing ample clearance for various workpieces. The Chevalier FSG-1224AD is equipped with a standard grinding wheel diameter of 14 inches and a width of 2 inches, featuring a hole diameter of 5 inches, making it suitable for a wide range of grinding tasks.

The machine offers both hydraulic and manual table longitudinal travel, with hydraulic travel reaching 25.625 inches and manual travel extending to 27.5 inches. Its table speed ranges from 16 to 82 feet per minute, ensuring efficient operation. Additionally, the FSG-1224AD includes a hydraulic table cross travel of 13.75 inches and a manual option of 14.125 inches, allowing for versatile machining capabilities. The rapid traverse speed is rated at 12.5 feet per minute, while the cross in-feeds range from 0.125 to 2 inches per revolution, with microfeed options providing precision down to 0.00005 inches per graduation. Powered by a 5 HP grinding wheel spindle motor, this surface grinder weighs 4,630 pounds and operates on a voltage of 230/460/3/60.

It also comes equipped with a chip conveyor for enhanced efficiency. If you have a 2005 Chevalier FSG-1224AD Surface Grinder that you are looking to sell, we invite you to contact us. We buy CNC machines and are prepared to offer you a competitive price for your equipment. Let us help you turn your surplus machinery into cash today!
