Direct procurement1985 Model

Sell your Chevalier CG-1260 Swing today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Chevalier
Model: CG-1260 Swing
Year: 1985
Category: CNC Grinding Machines
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Chevalier CG-1260 Swing Specifications

HYDRAULIC TANK CAPACITY: 16 GALLONS
MAXIMUM WORKPIECE WEIGHT: 330 LBS
MAXIMUM SWING OVER BED: 12.598 in
MAXIMUM GRINDING LENGTH: 59 in
TABLE MIN. TRAVERSE LENGTH: 0.3 in
TABLE HANDWHEEL PER REVOLUTION: 0.5 in
WHEEL HEAD GRINDING WHEEL SPEED: 1650 RPM
WHEEL HEAD MAX. PERIPHERY SPEED: 6480 FPM
WHEEL HEAD MAX. INFEED TRAVEL: 9.64 in
WHEEL HEAD MAX. GRINDING WHEEL TRAVEL: 7.87 in
WHEEL HEAD MAXIMUM SWIVEL: 30E
TAILSTOCK QUILL TRAVEL: 1 in
WHEELHEAD MOTOR: 5 H.P.
WORKHEAD MOTOR: 1 H.P.
HYDRAULIC MOTOR: 2 H.P.
COOLANT PUMP MOTOR: 1/4 H.P.
COOLANT MAGNETIC SEPARATOR MOTOR: 1/25 H.P.
INTERNAL GRINDING ATTACHMENT MOTOR: 1 H.P.
PACKING DIMENSIONS: 170 in X 83 in X 77 in H
SPINDLE PART #B80-5704/1 H.P. MOTOR/SPINDLE SPEED: 18,000 RPM
SPINDLE PART #B80-5704-1 / 1 H.P. MOTOR/SPINDLE SPEED: 12,000 RPM.

Do you have a Chevalier CG-1260 Swing to sell?

We are actively seeking a 1985 Chevalier CG-1260 Precision Universal Cylindrical Grinder. This exceptional machine boasts a maximum swing over the bed of 12.598 inches and a maximum grinding length of 59 inches, making it an ideal choice for precision grinding tasks. With a robust hydraulic tank capacity of 16 gallons, it efficiently handles workpieces weighing up to 330 lbs. The machine's wheel head operates at a grinding wheel speed of 1650 RPM, ensuring optimal performance and precision in every grind. The maximum periphery speed of the wheel head reaches 6480 FPM, allowing for fast and effective material removal. Additionally, the wheel head features a maximum infeed travel of 9.64 inches and a maximum grinding wheel travel of 7.87 inches, providing versatility for various grinding applications.

The Chevalier CG-1260 is equipped with a powerful 5 H. P. wheelhead motor and a 1 H. P. workhead motor, delivering reliable performance for demanding grinding tasks. The internal grinding attachment motor also offers 1 H. P., enhancing its capabilities. With a tailstock quill travel of 1 inch, this machine delivers precision and ease of use.

The machine's packing dimensions are 170 in X 83 in X 77 in H, making it suitable for shop environments where space may be a consideration. If you have a Chevalier CG-1260 or any other CNC grinding machine that you're looking to sell, we want to hear from you! At Superior Machine Tools, we specialize in buying used CNC machines and offer competitive prices. Contact us today to get a quote and turn your used equipment into cash.
