Make: Okuma
Model: LC-50
Year: 1999
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okuma LC-50 Specifications

# Of Axes: 4
Max Turning Diameter: 19.69" (500mm)
Max Turning Length: 29.63" (750mm)
X-Axis (Cross Travel of Upper Turret): 12.99+5.51" (330+140mm)
Z-Axis (Longitudinal Travel of Upper Turret): 80.31" (2,040mm)
X2-Axis (Cross Travel of Lower Turret): 10.04+.59" (255+15mm)
Main Spindle Thru Hole: 6.669" (190mm)
Main Spindle Horsepower: 60/75 HP
Main Spindle Speed Range: 10 - 1,500 RPM
X-Axis Upper Turret Cross Travel Feed Rates: .0001-39.37 IPR (.01-1000mm/rev)
X-Axis Upper Turret Cross Travel Rapid Traverse Rate: 196.85 IPM (5,000mm/min)
Z-Axis Upper Turret Longitudinal Travel Feed Rates: .0001-39.37 IPR (.01-1000mm/rev)
Z-Axis Upper Turret Longitudinal Rapid Traverse Rate: 393.7 IPM (10,000mm/min)
X2-Axis Lower Turret Head Cross Travel Feed Rates: .0001-39.37 IPR (.01-1000mm/rev)
X2-Axis Lower Turret Head Cross Travel Rapid Traverse Rate: 196.85 IPM (5,000mm/min)
Z2-Axis Lower Turret Head Longitudinal Travel Feed Rates: .0001-39.37 IPR (.01-1000mm/rev)
Z2-Axis Lower Turret Head Longitudinal Rapid Traverse Rate: 393.7 IPR (10,000mm/rev)
Upper Turret Positions: 12
Lower Turret Positions: 8
Bed Length of Upper Slideway: 86.22" (2,190mm)
Bed Width of Upper Slideway: 28.35" (720mm)
Bed Length of Lower Slideway: 86.22" (2,190mm)
Bed Width of Lower Slideway: 22.05" (560mm)
Hydraulic Tank Capacity: 10.6 Gal (40 R)
Approximate Machine Dimensions: 125" x 256"
Approximate Machine Height: 114"
Approximate Machine Weight: 41,500 LBS.

Do you have a Okuma LC-50 to sell?

We are actively seeking a 1999 Okuma LC-50 Big Bore Lathe. This impressive machine features the OSP-7000L CNC control system, providing precision and efficiency that shops appreciate. With a maximum swing of 31.5 inches and a turning diameter of 19.69 inches, the LC-50 is designed for versatility in various machining applications. It supports a maximum turning length of 29.63 inches, making it suitable for a wide range of workpieces.

Equipped with a robust 60/75 HP main spindle, this lathe can reach speeds of up to 1,500 RPM, allowing for rapid and effective machining processes. The machine also includes a 31.5-inch 3-jaw hydraulic chuck and features 12- and 8-position turrets, which enhance its capability to perform complex operations with ease. The X-axis and Z-axis travels provide significant cross and longitudinal travel ranges, ensuring that it can handle diverse machining tasks efficiently. The LC-50 also comes with a 22-inch chip conveyor and full enclosures, which not only improve the working environment but also facilitate maintenance and operation.

With assorted LC-50 tool holders included, this lathe is ready for immediate use, making it a valuable asset for any shop. Sellers often consider parting with their machines for various reasons, including upgrading to newer models, downsizing their operations, or even closing down a facility. Whether you're in the aerospace sector, a job shop, or any manufacturing industry, we're committed to providing a trustworthy and efficient selling experience. If you have a 1999 Okuma LC-50 or similar equipment that you're ready to sell, contact us today to discuss your options and receive a fair offer.
