Sell your Mazak INTEGREX-200-IV 2006 today.
Mazak INTEGREX-200-IV Specifications
| # Axis | 5 |
|---|---|
| 2nd Spindle Bore | 2.99" |
| 2nd Spindle RPM | 35-5000 |
| 2nd Spindle HP | 25 |
| A Axis Travel | 360° |
| A Axis Rapid Traverse | Not Provided |
| Approximate Dimensions | 160" x 93.0" x 110.2" High |
| Approximate Machine Weight | 22,660 lbs |
| ATC Capacity | 40 |
| Axes | 5 |
| Axis X | 22.83" |
| Axis Y | 6.30" |
| Axis Z | 41.14" |
| B Axis Travel | 225° |
| B Axis Milling Spindle Speed | Not Provided |
| C Axis Travel | 360° (0.001°) |
| Control Type | Mazatrol Matrix CNC |
| Maximum Cutting Diameter | 26.0" |
| Maximum Cutting Length | 40.0" |
| Maximum Tool Diameter | 3.54" |
| Maximum Tool Length | 11.81" |
| Tool Holder Type | HSK-63 Taper |
| Weight Capacity | 660 lbs |
| Workpiece Weight Capacity | 660 lbs |
| Workpiece Size | Not Provided |
| Spindle Speed Range | 35-5000 RPM |
| Spindle Motor Power | 30 HP |
| Tool Positions | 40 |
| Rapid Traverse Rate | Not Provided |
| Chip Removal System | Not Provided |
| Coolant System | Not Provided |
| Drive System Type | Not Provided |
| Control System Type | Mazatrol Matrix CNC |
| Software Compatibility | Not Provided |
| Other | Linear Ways Construction: Yes |
| EIA/ISO Programming | Yes |
| 3DCoordinate Conversion | Yes |
| Rigid Tapping | Yes |
| PCMCIA Card Slot | Yes |
| Main Spindle Nose | A2-8 |
| Sub Spindle Nose | A2-8 |
| Main Spindle Bore | 2.99" |
| Sub Spindle Bore | 2.99" |
| Main Spindle Motor | 30 HP |
| Sub Spindle Motor | 25 HP |
| Milling Head | Single Station Pendulum Head with 40 ATC |
| Max Tool Diameter | 3.54" |
| Max Tool Length | 11.81" |
| Spindle Speed | 15-12,000 RPM |
| Spindle Motor | 25 HP |
| Spindle 90° Index Time | 0.5 sec |
| Lower Turret | Capacity: 9 Stations |
| Turret Index Time | 0.14 Second |
| OD Tool Size | 1.00" |
| Power Source | AC 400V, Three Phase, 50/60 Hz |
| Power Requirement | 82.6 Kva. |
Do you have a Mazak INTEGREX-200-IV to sell?
We are actively seeking a 2006 Mazak INTEGREX-200-IV CNC Multi-Tasking Machine. This impressive machine is known for its versatility and efficiency, making it a valuable asset for any shop. With a maximum turning diameter of 26 inches and a turning length of 40 inches, the INTEGREX-200-IV is designed to handle a variety of machining tasks with ease. It features a robust main spindle that operates at speeds ranging from 35 to 5000 RPM, powered by a 30 HP motor, and a sub spindle with a similar speed range, driven by a 25 HP motor. This capability allows for high precision and productivity in both turning and milling operations.
Equipped with a single station pendulum milling head that includes a 40-tool automatic tool changer, this machine is ready to take on complex machining requirements. The Mazatrol Matrix CNC control system enhances user experience with EIA/ISO programming capabilities and 3D coordinate conversion, enabling seamless operation for machinists of all levels. The rapid traverse rates of 1496 inches per minute in the X and Z axes, along with 1093 inches per minute in the Y axis, ensure quick setup and turnaround times, which are critical in today's fast-paced manufacturing environments. We understand that many sellers choose to part with their machines for various reasons, such as upgrading to newer technology, downsizing their operations, or closing facilities altogether. If you find yourself in a similar situation, we can help you transition smoothly by offering a fair price for your equipment.
We pride ourselves on our ability to provide fast payments and handle all logistics, ensuring that selling your machine is as hassle-free as possible. At Superior Machine Tools, we buy nationwide, and we are particularly interested in high-quality machines like the 2006 Mazak INTEGREX-200-IV. Whether your machine has seen heavy use or is in excellent condition, we encourage you to reach out to us. Let us help you turn your idle equipment into cash while you focus on what matters most in your business.
