Mazak INTEGREX I300IISR 1500 W/ GL200 GANTRY (2012)

Direct procurement2012 Model

Sell your Mazak INTEGREX I300IISR 1500 W/ GL200 GANTRY today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: INTEGREX I300IISR 1500 W/ GL200 GANTRY
Year: 2012
Category: CNC Multi-Tasking Machines (Mill-Turn / Turn-Mill)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak INTEGREX I300IISR 1500 W/ GL200 GANTRY Specifications

# Axis: 5
2nd Spindle Bore: 3.59"
2nd Spindle Chuck: 10"
2nd Spindle HP: 35 HP
2nd Spindle RPM: 4000 RPM
B Axis Head Indexing: -30 ~ +210 DEGREES
B Axis Milling Spindle Speed: 12,000 RPM
B Axis Milling Spindle Taper: CAPTO C6
B Axis Milling Spindle Horse Power: 35 HP
ATC Capacity: 72 ATC
Tool Diameter: 3.54", 4.92"
Tool Length: 15.7"
Tool Weight: 26.46 LBS.
Axis X: 24.21"
Axis Z: 62.4"
Axis Y: 9.84"
C Axis Indexing: .0001
W Axis Travel Sub Spindle: 61.5"
Rapid Traverse Rate X: 1969 IPM
Rapid Traverse Rate Y: 1575 IPM
Rapid Traverse Rate Z: 1969 IPM
Approximate Machine Weight: 33,510 LBS.
Other: Swing Over Bed: 25.9"
Turning Diameter: 25.9"
Turning Length: 59.8"
Distance Between Spindles: 61.8"
Spindle Nose 1: A2 - 8
Spindle Bore Diameter 1: 3.59"
Bar Capacity 1: 3.15"
Spindle Speeds 1: 4000 RPM
Spindle Horsepower 1: 40 HP
Chuck Size 1: 10"
C Axis Indexing 2: .0001"
Chuck Size 2: 10"
W Axis Travel Sub Spindle: 61.50"
Other: Y Axis Travel Y1, Y2, Y3: 9.84"
Other: Machine Weight: 33,510 LBS.
Other: Tool Positions: 72
Other: Rapid Traverse Rates X1, X2, X3: 1969 IPM
Other: Rapid Traverse Rates Y1, Y2, Y3: 1575 IPM
Other: Rapid Traverse Rates Z1, Z2, Z3: 1969 IPM.

Do you have a Mazak INTEGREX I300IISR 1500 W/ GL200 GANTRY to sell?

We are actively seeking a 2012 MAZAK INTEGREX I300IISR 1500 W/ GL200 GANTRY CNC multi-tasking machine. This model stands out with its impressive specifications, making it a valuable asset for any machining operation. With a swing over bed of 25.9 inches and a turning diameter of the same size, this machine is designed for versatility and efficiency. The turning length reaches up to 59.8 inches, while the distance between spindles is 61.8 inches, allowing for complex operations without needing to reposition the workpiece frequently.

Equipped with dual spindles, both featuring A2-8 nose designs and a spindle bore diameter of 3.59 inches, this machine operates at spindle speeds of up to 4000 RPM, delivering powerful performance with spindle horsepower rated at 40 HP and 35 HP for each spindle respectively. The B-axis head indexing offers a range of -30 to +210 degrees, enhancing its milling capabilities, and with a B-axis milling spindle speed of 12,000 RPM, this machine can handle a variety of materials and complex geometries. The tool changer for the milling spindle boasts a capacity of 72 tools, with tool diameters ranging from 3.54 to 4.92 inches, and a tool weight capacity of 26.46 lbs. The X-axis travel measures 24.21 inches, while the Z-axis travel is an impressive 62.4 inches, complemented by a Y-axis travel of 9.84 inches.

This configuration makes it suitable for a wide array of machining tasks, from precision parts manufacturing to intricate designs. Sellers often part with machines like this due to reasons such as upgrading to newer technology, downsizing their operations, or even plant closures. Whatever the reason, we understand the importance of a smooth and efficient selling process. If you have a 2012 MAZAK INTEGREX I300IISR 1500 W/ GL200 GANTRY or similar CNC machine, we would love to discuss your options and help you through the selling process.
