Direct procurement2010 Model

Sell your Mazak GL150F today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: GL150F
Year: 2010
Category: CNC Multi-Tasking Machines (Mill-Turn / Turn-Mill)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak GL150F Specifications

Power: Main Spindle Drive: 30 HP, Sub Spindle Drive: 25HP, Milling Head Drive: 25 HP
Max Swing Over Lower Turret: 26"
Max Swing Over Cross Slide: 26"
Max Machining Diameter Upper: 26"
Max Machining Diameter Lower: 10.6"
Max Machining Length: 58.86"
Maximum Bar Capacity: 2"
Main Chuck Od: 8"
Main Spindle Speeds: 35-5,000 RPM
Main Spindle Nose / Bore: A2-6
Main Spindle Indexing: Full C-axis (0.0001 Degree)
Second Chuck Od: 8"
Second Spindle Speeds: 35-5,000 RPM
Second Spindle Indexing: Full C-Axis (0.0001 Degree)
Second Spindle Headstock Stroke (W Axis): 61.02"
Second Spindle Rapid Traverse Rate: 1,181 IPM (W)
Milling Spindle Speed: 12,000 Max RPM
Milling Spindle B-Axis Programmable: 225 Degrees (120 Deg Left / 105 Deg Right)
Milling Spindle Travel X: 22.83"
Milling Spindle Travel Z: 60.82"
Milling Spindle Travel Y: +/- 3.15"
Milling Spindle Taper: KM63 Taper
Rapid Traverse Rates Milling Spindle (X / Z): 1,496 IPM
Automatic Tool Changer Capacity for Milling Spindle: 40 Station
Automatic Tool Changer Speed: 1.3 Seconds Tool to Tool
Max Tool Diameter: 3.54"
Max Tool Length: 4.92"
Max Tool Weight: 22 Lbs.
Lower Turret Travels X: 5.91"
Lower Turret Travels Z: 58.66"
Lower Turret Capacity: 9 Stations
Lower Turret Index Time: .14 Seconds Per Step
Lower Turret Rapid Traverse Rate X: 1,496 IPM
Coolant Capacity: 120 Gallons.

Do you have a Mazak GL150F to sell?

We are actively seeking a 2010 Mazak GL150F, a versatile and powerful CNC multi-axis mill-turn lathe that combines exceptional machining capabilities with advanced technology. This machine features a maximum swing of 26 inches and is designed for impressive upper and lower machining diameters of 26 inches and 10.6 inches respectively. With a maximum machining length of 58.86 inches and a maximum bar capacity of 2 inches, the GL150F is equipped to handle a variety of complex machining tasks with ease. The main spindle chuck size is 8 inches, allowing for robust workholding, while the spindle speeds range from 35 to an impressive 5,000 RPM. It also boasts full C-axis indexing with a precision of 0.0001 degrees, providing the accuracy required for intricate parts.

The 30 HP main spindle drive ensures that this machine can handle demanding workloads efficiently. The second spindle also features an 8-inch chuck size and matches the main spindle's speed capabilities, offering similar indexing precision. With a sub spindle drive of 25 HP and a headstock stroke of 61.02 inches, this lathe can significantly enhance productivity. The milling head operates at a maximum speed of 12,000 RPM and incorporates a programmable B-axis with a range of 225 degrees, allowing for dynamic machining strategies. Equipped with a 40-station automatic tool changer that operates at a rapid tool-to-tool speed of just 1.3 seconds, the GL150F is designed for efficiency and precision.

The lower turret features 9 stations and offers rapid traverse rates of 1,496 IPM, ensuring swift transitions between operations. If you have a 2010 Mazak GL150F that you are considering selling, we are here to offer you a competitive price. Contact us today to discuss how we can help you turn your equipment into cash!
