Sell your Gleason 400GH today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Gleason
Model: 400GH
Category: CNC Gear Machinery
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Gleason 400GH Specifications

Axis Speed X: 197”/Min
Axis Speed Y: 197”/Min
Axis Speed Z: 197”/Min
Coolant System: Self-contained coolant pump, tank, & piping, with magnetic chip conveyor
Control System: FANUC Model 150MB computer control with color CRT and gear cutting software, with automatic setup and control of 6 axes
Maximum Axial Travel: 33.47” (850mm)
Maximum Normal Module: 5-150 rpm Optional
Approx Net Weight: 26,800 Lbs (12,188 Kg)
Other: with operator’s controls at front of machine, adjacent to operator’s access
Other: Support column & hydraulic tailstock arm with 180-degree swivel base
Other: Control software package w/user-friendly conversational dialogue, (in English)
Other: Security key for control of setup
Other: Full complement of electrics (motors/controls)
Other: Replacement parts list, hydraulic and electrical diagrams, etc.
Other: Maximum weight of part accepted
Other: Work-spindle bore taper: Gleason #50 Taper
Other: Work-spindle Speed: 1 to 75 rpm
Other: Max. rapid traverse rate (Axial): 197”/Min (5000mm/min)
Other: Max. rapid traverse rate (Radial): 197”/Min (5000mm/min)

Do you have a Gleason 400GH to sell?

We are actively seeking a GLEASON 400GH Gear Hobbing Machine. This model, known for its high performance in CNC gear manufacturing, is a valuable asset for any shop specializing in the production of gears, pinions, splines, and worm gears. With its operator's controls conveniently located at the front of the machine, operators can easily access the features that enhance productivity. The GLEASON 400GH is equipped with a self-contained coolant pump and tank, along with a magnetic chip conveyor that ensures a clean working environment, which is crucial for maintaining precision during operations. This model features a FANUC Model 150MB computer control with a color CRT display, allowing for seamless interaction through user-friendly conversational dialogue in English.

The robust control software provides automatic setup and control of six axes, which significantly streamlines the gear cutting process. The machine's work-spindle bore taper is a Gleason #50 taper, supporting a maximum work-spindle speed of 1 to 75 RPM, with an optional upgrade to 5-150 RPM for enhanced versatility. The rapid traverse rates are impressive, with both axial and radial capabilities reaching up to 197 inches per minute, ensuring efficiency in production cycles. The GLEASON 400GH can accommodate parts with a maximum weight of 33.47 inches at the tailstock spindle bearing face, making it suitable for a variety of gear sizes. Its net weight without a carousel loader is approximately 26,000 lbs, which speaks to its robust construction and reliability.

Sellers often part with machines like the GLEASON 400GH for various reasons, including upgrades to newer technology, downsizing operations, or even plant closures. Whatever your reason for considering a sale, we understand the importance of a smooth transition. If you own a GLEASON 400GH or similar equipment and are ready to sell, we would love to hear from you!
