Direct procurement2007 Model

Sell your DMG MORI NT4300 DCG/1500S today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: DMG MORI
Model: NT4300 DCG/1500S
Year: 2007
Category: CNC Multi-Tasking Machines (Mill-Turn / Turn-Mill)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

DMG MORI NT4300 DCG/1500S Specifications

Swing Over Bed: 28.7"
Turning Diameter: 28.7" / 15.7"
Turning Length: 58.9"
Distance Between Spindles: 73.3"
Chuck Size: 12"
Spindle Nose: A2-8
Spindle Bore Diameter: 4.1"
Bar Capacity: 3.5"
Spindle Speeds: 2500 RPM
Spindle Horsepower: 40 HP
B - Axis Head Indexing: .0001 Degree
B - Axis Milling Spindle Speed: 12,000 RPM
B - Axis Milling Spindle Taper: Capto C6
B - Axis Milling Spindle Horse Power: 24.7 HP
ATC For Milling Spindle: 240 ATC
Tool Diameter: 2.7" / 5.5"
Tool Length: 15.7"
Tool Weight: 22 Lbs.
X - Axis Travel: 29.5"
Z - Axis Travel: 61"
Y - Axis Travel: +/- 8.3"
C - Axis Indexing: .0001 Degree
W - Axis Travel Sub Spindle: 63"
Rapid Traverse Rates X1, X2, X3: 1968, 1181 IPM
Rapid Traverse Rates Y1, Y2, Y3: 1181 IPM
Rapid Traverse Rates Z1, Z2, Z3: 1968, 1181 IPM
Machine Weight: 62.250 Lbs.

Do you have a DMG MORI NT4300 DCG/1500S to sell?

We are actively seeking a 2007 DMG MORI NT4300 DCG/1500S, a sophisticated mill-turn machine designed for precision and efficiency in multi-tasking operations. This robust CNC multi-tasking machine boasts a swing over bed of 28.7 inches and a turning diameter of 28.7 inches, allowing for versatile machining capabilities. With a turning length of 58.9 inches and a distance between spindles measuring 73.3 inches, it is well-suited for handling larger workpieces with ease. Equipped with two 12-inch chucks, this machine features A2-8 spindle noses and a spindle bore diameter of 4.1 inches for optimal performance. The NT4300 DCG/1500S achieves impressive spindle speeds of up to 2500 RPM and is powered by dual 40 HP spindles, ensuring that you can tackle demanding tasks with confidence.

The B-axis head indexing, precise to .0001 degrees, enhances the machine's versatility, allowing for complex milling operations with a B-axis milling spindle speed of 12,000 RPM. This spindle is fitted with a Capto C6 taper and delivers 24.7 HP, making it capable of handling various tooling requirements. The automatic tool changer (ATC) for the milling spindle supports up to 240 tools, accommodating a wide range of tool diameters and lengths. With substantial travels across the X, Y, and Z axes - 29.5 inches in X1, +/- 8.3 inches in Y, and up to 61 inches in Z - this machine offers significant flexibility. The rapid traverse rates of 1968 IPM in the X and Z axes ensure swift movement, enhancing productivity.

Weighing in at 62,250 lbs, the NT4300 DCG/1500S is built to last, providing reliability in demanding manufacturing environments. If you have a 2007 DMG MORI NT4300 DCG/1500S that you are looking to sell, contact us today. We specialize in purchasing used CNC machines and can offer you a competitive price for your equipment.
