Direct procurement

Sell your DMG MORI NT-4200/1000S today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: DMG MORI
Model: NT-4200/1000S
Category: CNC Multi-Tasking Machines (Mill-Turn / Turn-Mill)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

DMG MORI NT-4200/1000S Specifications

# Axis: 5
2nd Spindle Bore: 2.99″
2nd Spindle RPM: 35-5000 RPM
2nd Spindle Power: 22 kW
Axis X: 29.5″
Axis Z: 44.1″
Axis Y: 8.3″
Axis W: 41.34″ (Sub Spindle)
Axis C: 360° (0.001°) Both Spindle
Axis B: +/-120°
Rapid Traverse Rate: X Axis: 1417 IPM, Z Axis: 1417 IPM, Y Axis: 1351 IPM, B Axis: 1181 IPM
Main Spindle Bore: 2.99″
Main Spindle Nose: A2-6
Main Spindle Speed: 35-5000 RPM
Main Spindle Power: 22 kW
Sub Spindle Bore: 2.99″
Sub Spindle Nose: A2-6
Sub Spindle Speed: 35-5000 RPM
Sub Spindle Power: 22 kW
Tool Type: CAPTO-C6, 40 Taper
Spindle Speed: 15-12000 RPM
Spindle Motor Power: 18.5 kW
Index Time: 0.5 sec
Power: 87 kVA, 220V / 3-Phase
Air Requirements: 71 PSI Overall
Approximate Dimensions: 192″ x 99″ x 110″
Approximate Machine Weight: 46,500 lbs
Other: No Charges for loading at list Price.

Do you have a DMG MORI NT-4200/1000S to sell?

We are actively seeking a DMG MORI SEIKI NT-4200/1000S CNC multi-tasking machine. This remarkable piece of equipment is designed for versatility in machining, combining both milling and turning capabilities to meet the diverse needs of modern manufacturing. The NT-4200/1000S features a maximum turning diameter of 25.9 inches and a max turning length of 42.5 inches, making it suitable for a wide range of applications. With a maximum swing of 28.7 inches and a Y-axis travel of 8.3 inches, this machine offers the flexibility that shops require to tackle complex jobs efficiently. Equipped with dual spindles, the NT-4200/1000S has a maximum bar capacity of 2.625 inches for the main spindle and 2.55 inches for the sub spindle, allowing for seamless operation on various workpieces.

The machine's robust construction supports a maximum weight of 1,322 lbs on both spindles, ensuring stability during operation. The impressive rapid traverse rates of 1,417 IPM on the X and Z axes and 1,351 IPM on the Y axis guarantee fast cycle times, which can significantly enhance productivity in your shop. The main and sub spindles both operate at speeds ranging from 35 to 5,000 RPM, providing the power needed for high-performance machining. Additionally, the single station pendulum head with a 40-tool automatic tool changer (ATC) streamlines tool management, allowing for quick transitions between tasks. The spindle speed of up to 12,000 RPM further enhances the machine's capability to handle diverse materials with precision.

Sellers often part with machines like the NT-4200/1000S for various reasons, including upgrading to newer technology, downsizing operations, or closing facilities altogether. If you're ready to sell your DMG MORI SEIKI NT-4200/1000S or any other CNC machine, reach out to us today. We are committed to providing a trustworthy and efficient service to all our sellers.
