Direct procurement

Sell your Starrag 2VC2800/280MC-FC-V today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Starrag
Model: 2VC2800/280MC-FC-V
Category: CNC Vertical Turret Lathes (VTL)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Starrag 2VC2800/280MC-FC-V Specifications

Table diameter: 2800mm
Swing: 3350mm
Maximum table load: 35 tonnes
Maximum height under ram: 3100mm
Main drive motor: 2 x 60Kw
Table speeds: 1.6-180Rpm
Cutting force on turning tool: 50Kn
Ram section: 250x250mm
Live spindle drive motor: 30Kw
Live spindle speeds: 20-4000Rpm
Z-AXIS (Ram traverse): 1500mm
C-AXIS (table rotation for milling) Speed: 0-3Rpm
C-AXIS Circular feed: 0.001-1080 degrees per minute
X-AXIS (Saddle traverse along cross rail): 1550mm left / 1950mm right
Saddle cross-feed rate: up to rapids 18m/min
Y-AXIS (Table traverse): 2800mm - 1400mm each in/out from centre
V-AXIS (Crossrail rise fall for positioning): in increments of 100mm - total 900mm
Crossrail rise and fall traverse speed: 425mm/min
Electrics Operating voltage: 380/415v or 460v
Control voltage: 24vDC
Frequency: 50Hz
Total connected power load: approximately 175Kva.

Do you have a Starrag 2VC2800/280MC-FC-V to sell?

We are actively seeking a used Starrag 2VC2800/280MC-FC-V Vertical Boring Mill to add to our inventory. This exceptional machine, designed for heavy-duty applications, boasts an impressive table diameter of 2800mm and a swing of 3350mm, making it ideal for large-scale machining tasks. With a maximum table load capacity of 35 tonnes and a maximum height under ram of 3100mm, this machine is built to handle substantial workpieces with ease. The dual 60Kw main drive motors provide robust power, while the table speeds range from 1.6 to 180 RPM, allowing for versatile operations across various materials.

The cutting force on the turning tool reaches 50Kn, ensuring efficient material removal during machining processes. Equipped with a live spindle drive motor of 30Kw, the Starrag 2VC2800/280MC-FC-V offers live spindle speeds from 20 to 4000 RPM, making it suitable for both turning and milling applications. The Z-axis ram traverse extends to 1500mm, while the C-axis allows for table rotation speeds of up to 3 RPM and a circular feed ranging from 0.001 to 1080 degrees per minute. The X-axis features a saddle traverse of 1550mm left and 1950mm right, while the Y-axis provides a table traverse of 2800mm, allowing for precise positioning and movement.

Additionally, the V-axis enables crossrail rise and fall with a total of 900mm in increments of 100mm, ensuring adaptability for various workpiece sizes. With a total connected power load of approximately 175Kva and operating voltages of 380/415v or 460v, this machine is designed for efficiency and reliability. If you have a Starrag 2VC2800/280MC-FC-V that you are looking to sell, we invite you to contact us for a fair and competitive evaluation. Let us help you maximize the value of your used CNC machinery.
