Direct procurement1994 Model

Sell your Poreba TR135-B2/10M Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Poreba
Model: TR135-B2/10M Year
Year: 1994
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Poreba TR135-B2/10M Year Specifications

Maximum Distance Between Centers: 396"
Swing Over Bed: 53"
Swing Over Cross Slide: 41"
Swing in Gap: 65"
Length of Gap from Spindle Nose: 22"
Bed Width: 25.98"
Spindle Hole Diameter: 4.72"
Spindle Nose: A1-15
Spindle Speeds: 5 - 500 RPM
Feeds – Longitudinal: 0.0035" - 0.400" TPR
Cross Slide Feeds: 0.0017 to 0.200 TPR
Top Slide Feeds: 0.0008 to 0.100 TPR
Threads - Inch: 1/2 to 60 TPI
Threads - Metric: 1 – 120 mm/Rev
Cross Slide Travel: 20-3/4"
Tailstock Spindle Diameter: 7-1/2"
Tailstock Travel: 12"
Maximum Weight Between Centers Unsupported: 20,000 Lbs
Maximum Weight Between Centers With (1) Steady: 22,100 Lbs
Maximum Weight Between Centers With (2) Steadies: 26,500 Lbs
Main Motor: 55 HP
Approximate Dimensions: 65.5' (L) x 9.41' (W)
Approximate Weight: 42,240 Lbs
Equipped With: 32" 4 Jaw Chuck, Live Center Built into Tailstock, Hardened and Ground Bed Ways, Coolant system, 5 Roller Type Steady Rests, Power Rapid Traverse.

Do you have a Poreba TR135-B2/10M Year to sell?

We are actively seeking a 1994 Poreba TR135-B2/10M CNC lathe, a remarkable machine known for its robust construction and versatility. This gap bed lathe features a maximum distance between centers of 396 inches and a swing over bed of 53 inches, making it ideal for handling large workpieces. With a swing over cross slide of 41 inches and a swing in gap of 65 inches, this lathe is designed to accommodate a variety of machining tasks efficiently. It boasts a bed width of 25.98 inches and a spindle hole diameter of 4.72 inches, ensuring stability and precision during operation.

The A1-15 spindle nose allows for easy tooling changes, while the spindle speeds ranging from 5 to 500 RPM provide flexibility for different machining requirements. The longitudinal feeds vary from 0.0035 to 0.400 TPR, and cross slide feeds range from 0.0017 to 0.200 TPR, allowing for fine adjustments and smooth operation. Additionally, the TR135-B2/10M can handle substantial weights, with a maximum unsupported weight of 20,000 lbs and up to 26,500 lbs with steady rests. Equipped with a powerful 55 HP main motor, this machine is built to perform under demanding conditions.

The approximate dimensions of 65.5 feet in length and 9.41 feet in width, along with an approximate weight of 42,240 lbs, signify its industrial strength. This lathe also features a 32-inch 4-jaw chuck, live center built into the tailstock, hardened and ground bed ways, a coolant system, and power rapid traverse. If you are looking to sell your 1994 Poreba TR135-B2/10M, contact us today to receive a competitive offer and ensure your machinery finds a new home with a buyer who appreciates its value.
