Direct procurement2006 Model

Sell your Okuma CAPITAN-L470M today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Okuma
Model: CAPITAN-L470M
Year: 2006
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Okuma CAPITAN-L470M Specifications

Max Turning Diameter: 16.53"
Max Turning Length: 25.59"
Swing Over Slide: 18.89"
Swing Over Bed: 24.40"
Max Bar Capacity: 3.99"
X Axis Travel: 11.81"
Z Axis Travel: 26.57"
Rapid Traverse X Axis: 787 IPM
Rapid Traverse Z Axis: 984 IPM
Spindle Nose: A2-11
Spindle Bore: 4.33"
Spindle Speed: 3,000 RPM
Spindle Motor: 30 HP
Turret Capacity: 12 Stations
Live Tool Speed: 3,000 RPM
Live Tool Motor: 7.5 HP
Turret Index Time: 1 Second
Tailstock Taper: MT-5
Tailstock Quill Diameter: 3.94"
Tailstock Quill Stroke: 5.90"
Power Source: AC 220/480 V, Three Phase, 60 Hz
Power Requirement: 29.5 kva
Floor Space: 106" x 74"
Weight: 12,200 lbs Approx.
Tool Holders Type: VDI

Do you have a Okuma CAPITAN-L470M to sell?

We are actively seeking a 2006 Okuma Capitan-L470M, a premier live tooling lathe designed for precision and efficiency in CNC machining. With a maximum turning diameter of 16.53 inches and a maximum turning length of 25.59 inches, this machine is perfect for a variety of turning applications. The Capitan-L470M boasts a swing over bed of 24.40 inches and a swing over slide of 18.89 inches, allowing for versatile setups and larger workpieces. Equipped with a robust A2-11 spindle nose, the lathe features a spindle bore of 4.33 inches and can achieve spindle speeds of up to 3,000 RPM.

Its powerful 30 HP spindle motor ensures high-performance machining, while the turret capacity of 12 stations allows for efficient tool changes with a turret index time of just 1 second. The live tooling functionality, supported by a dedicated 7.5 HP motor and capable of reaching 3,000 RPM, enables complex machining operations without the need to reposition the workpiece. With X and Z axis travels of 11.81 inches and 26.57 inches respectively, along with rapid traverse rates of 787 IPM in the X axis and 984 IPM in the Z axis, the Capitan-L470M is built for speed and precision. This machine also features a tailstock taper of MT-5, providing added versatility for various machining tasks.

Measuring 106 inches by 74 inches and weighing approximately 12,200 lbs, this lathe fits into a range of shop environments. If you have an Okuma Capitan-L470M that you are looking to sell, we invite you to contact us today. Our team at Superior Machine Tools is ready to make you a competitive offer and help facilitate a smooth transaction.
