Direct procurement2011 Model

Sell your Mazak QTN 100-II today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: QTN 100-II
CNC Control: CNC (MAZATROL MATRIX NEXUS)
Year: 2011
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak QTN 100-II Specifications

Chuck Size: 6"
Chuck Type: Hydraullic
Spindle Motor: 15 hp
Spindle Speeds: 6000 RPM
Spindle Bore/Bar Capacity: 1.97 in
Max Bar Capacity: 1.625"
Turret Tool Positions: 12
High Pressure Coolant System: 118 PSI
Chip Conveyor: Yes, Side
Parts Catcher: Yes
Control: CNC (MAZATROL MATRIX NEXUS)
Weight: 7270 LBS
Max Swing: 21.6"
Max Turning Diameter: 11"
Machining Length: 12.1"
X Travel: 7.5"
Z Travel: 13"
Rapid Traverse X: 1181 IPM
Rapid Traverse Z: 1299 IPM
Stroke of Tailstock Body: 13.7 IN
Spindle Drive Motor: AC 10/15 HP
Machine Weight: 7270 LBS.
Other: Tailstock: Yes
Spindle Nose: A2-5
Turret Type: Drum
Tool Capacity: 12.

Do you have a Mazak QTN 100-II to sell?

We are actively seeking a 2011 MAZAK QTN 100-II 2-Axis CNC Lathe. This model is well-regarded in the industry for its impressive specifications and reliability. With a maximum swing of 21.6 inches and a maximum turning diameter of 11 inches, the QTN 100-II is designed to handle a variety of machining tasks with ease. The spindle bore allows for bar capacity of up to 1.625 inches, making it versatile for different applications. The Z travel measures 13 inches while the X travel reaches 7.5 inches, providing sufficient range for complex machining operations. With a machining length of 12.1 inches, this lathe can tackle both small and larger components effectively.

Equipped with a robust 15 hp spindle motor, the QTN 100-II boasts spindle speeds of up to 6,000 RPM, enabling efficient cutting and shaping of materials. Its hydraulic chuck, sized at 6 inches, ensures secure gripping of workpieces while the turret offers 12 tool positions, allowing for quick tool changes during production. The high-pressure coolant system, operating at 118 PSI, aids in maintaining optimal temperatures during machining, thus enhancing the quality of the finished product. Many sellers part with machines like the MAZAK QTN 100-II for various reasons. Some may be upgrading to newer models with advanced features, while others may be downsizing their operations or even closing their facilities altogether. In some cases, machines may simply be underused and owners recognize the opportunity to liquidate assets that no longer serve their business needs.

At Superior Machine Tools, we understand that selling your equipment can be a significant decision. We aim to make the process as seamless as possible. If you own a 2011 MAZAK QTN 100-II or similar CNC lathe and are considering selling, we encourage you to reach out to us. Our team is ready to assist you in getting the best value for your machine, ensuring a smooth and efficient transaction.
