Direct procurement1997 Model

Sell your Mazak 650N today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: 650N
Year: 1997
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak 650N Specifications

Max Cutting Diameter: 24.40''
Max Distance Between Spindles: 76.78''
Standard Cutting Diameter: 18.10''
Spindle Nose: A2-8''
Spindle Bore: 3''
Spindle Speed: 35-2800 RPM
Spindle Power: 50 AC HP
2Nd Spindle Power: 40 AC HP
Turret Positions: 10
Rotary Tool Speed: 1500 RPM
Rotary Tool Power: 20 AC HP
Number Of Tools: 10
X Axis Stroke: 14.4''
Z Axis Stroke: 29.7''
C Axis Travel: 0.001
Rapid Traverse Rate X & Z: 709 & 787 IPM
Maximum Spindle Speed: 2800 RPM
Machine Weight: 45,980 LBS.

Do you have a Mazak 650N to sell?

We are actively seeking a 1997 MAZAK 650N Big Bore Lathe. This robust CNC lathe is designed for heavy-duty applications and is a perfect fit for various manufacturing needs. With a maximum swing diameter of 24.40 inches and a maximum distance between spindles of 76.78 inches, this machine is capable of handling large workpieces with ease. The standard cutting diameter of 18.10 inches ensures that you can tackle a wide range of turning tasks efficiently. Equipped with a powerful spindle that operates at speeds ranging from 35 to 2800 RPM, the MAZAK 650N is ideal for both roughing and finishing operations.

Its spindle motor, with a main horsepower of 50 AC HP and a sub horsepower of 40 AC HP, provides the necessary torque for demanding applications. This model features a 10-position drum turret on both the main and sub-spindle, allowing for quick tool changes and increased productivity. Additionally, the rotary tool speed of 1500 RPM and 20 AC HP power ensure versatility in machining operations. The travel capabilities of the MAZAK 650N are impressive, with an X-axis stroke of 14.4 inches and a Z-axis stroke of 29.7 inches, making it suitable for a variety of workpieces. The rapid traverse rates of 709 IPM in the X-axis and 787 IPM in the Z-axis enable fast positioning, enhancing overall efficiency in your shop.

With a machine weight of 45,980 lbs, this lathe is built to withstand rigorous usage and maintain stability during operations. Sellers often choose to part with machines like the MAZAK 650N for several reasons, including upgrading to newer technology, downsizing operations, or liquidating assets during a plant closure. If you find yourself in any of these situations, we are here to help. If you have a 1997 MAZAK 650N Big Bore Lathe or similar CNC equipment to sell, don't hesitate to reach out. We are ready to assist you in getting the best value for your machine.
