Mazak qtn 100 ii 2 axis cnc lathe 7 5 x 13 z 21 6 swing 12 turning length 6 chuck 15 hp 6000 rpm 12 tool mazatrol matrix nexus (2006)

Direct procurement2006 Model

Sell your Mazak qtn 100 ii 2 axis cnc lathe 7 5 x 13 z 21 6 swing 12 turning length 6 chuck 15 hp 6000 rpm 12 tool mazatrol matrix nexus today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: qtn 100 ii 2 axis cnc lathe 7 5 x 13 z 21 6 swing 12 turning length 6 chuck 15 hp 6000 rpm 12 tool mazatrol matrix nexus
Year: 2006
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak qtn 100 ii 2 axis cnc lathe 7 5 x 13 z 21 6 swing 12 turning length 6 chuck 15 hp 6000 rpm 12 tool mazatrol matrix nexus Specifications

Total Power Required (Machine Only): 22 kVA
Rapid Traverse X: 1181 IPM
Z: 1299 IPM
Max Cutting Length: 12.1"
Maximum Part Load: 7,700 lbs
X-Axis Travel: 7.5"
Horsepower Of Rotary Head: 15 HP
Machine Dimensions Lxwxh: 83" x 67" x 79"
Main Spindle Bore: 2.4"
Spindle Speed: 6000 RPM
Chuck Quantity: 1
Turrets #1 & #2: 12 position
Spindle Bar Capacity: 1.63"
Spindle Horsepower (Cont/30 Mins.): 15 HP
Spindle Nose: A2-5
Square Tool Shank Size: 1.25"
Tailstock Quill Travel: 12.0"
Machine Weight: 7,700 lbs

Do you have a Mazak qtn 100 ii 2 axis cnc lathe 7 5 x 13 z 21 6 swing 12 turning length 6 chuck 15 hp 6000 rpm 12 tool mazatrol matrix nexus to sell?

We are actively seeking a 2006 Mazak QTN-100-II, a robust 2-Axis CNC Lathe that combines precision and power for your machining needs. This model features a maximum swing diameter of 21.6 inches and a turning length of 12.1 inches, making it ideal for a variety of applications. With a chuck size of 6 inches and a spindle bore diameter of 2.4 inches, it offers versatility in handling different workpieces. The machine is powered by a 15 HP main spindle motor, capable of reaching spindle speeds of up to 6000 RPM, ensuring efficient operation for high-volume production.

The X-axis travel measures 7.5 inches, while the Z-axis travel extends to 13.0 inches, allowing for precise positioning and movement during machining processes. With a rapid feed rate of 1181 IPM in the X-axis and 1299 IPM in the Z-axis, this lathe is designed for quick setups and fast cycle times. The QTN-100-II is equipped with a Mazatrol Matrix Nexus control system, providing user-friendly programming and operation. It also features 12 tool stations, accommodating various tooling needs with a square tool shank size of 1.25 inches.

Weighing in at 7,700 lbs, and with dimensions of 83 x 67 x 79 inches without the conveyor, this machine is built to last. If you are looking to sell your 2006 Mazak QTN-100-II, we are here to offer you a competitive price. Contact us today for a quote and let us help you turn your used CNC lathe into cash!
