Sell your Mazak INTEGREX-100-IVST today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Mazak
Model: INTEGREX-100-IVST
Year: 2013
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Mazak INTEGREX-100-IVST Specifications

Travels: X-Axis: 16.14"
Z-Axis: 31.69"
Center distance: 30"
Swing over bed: 21.46"
Length - maximum: 29.65"
Diameter - maximum: 21.46"
Bar capacity (Spindle/Sub-Spindle): 2.00"
Bore: 2.40"
Speed (Spindle/Sub-Spindle): 6,000 RPM
Motor (Spindle/Sub-Spindle): 15 HP
Nose (Spindle/Sub-Spindle): A2-5
Speed (Rotary Tool Spindle): 12,000 RPM
Size (Rotary Tool Spindle): CAT40
ATC positions (Rotary Tool Spindle): 40
Motor (Rotary Tool Spindle): 7.5 HP
Positions (Lower Turret): 9
Machine dimensions: 144"(L-R) X 92”(F-B) X 89”(H)
Machine weight: 16,940 Lbs.
Chuck type (Spindle/Sub-Spindle): Collet
Type (Lower Turret): Drum
Equipped with: Mazatrol Matrix CNC Control, Synchronized Tapping, Inch/Metric Conversion, EIA/ISO Code Input Function, 3D Coordinate Conversion, Absolute Positioning System, XYZ Pitch Error Compensation Input, EIA Dynamic Compensation, Mazacc-3D High Speed Software Pkg., Tool Tip Point Control & Tool Radius Comp., C1+C2 Synchronous Function, Royal auto chuck on main and secondary spindle, Thru-Spindle Coolant, 213 PSI coolant, Chip Conveyor.

Do you have a Mazak INTEGREX-100-IVST to sell?

We are actively seeking a 2013 Mazak INTEGREX-100-IVST, a state-of-the-art multi-tasking CNC lathe that boasts exceptional capabilities for precision machining. This model features a maximum swing over bed of 21.46 inches and a swing over the cross slide of 13.86 inches, making it ideal for a variety of workpieces. With a bar capacity of 2 inches and a bore of 2.40 inches, it is designed to handle substantial materials efficiently. The INTEGREX-100-IVST is powered by dual spindles that can reach speeds of up to 6,000 RPM, complemented by a rotary tool spindle that operates at an impressive 12,000 RPM, ensuring high productivity in your machining operations.

The machine is equipped with a Mazatrol Matrix CNC Control that simplifies programming and operation, allowing for intuitive control over the machining process. Additionally, the lower turret features 9 positions, enhancing its versatility for complex parts. With dimensions of 144 inches in length, 92 inches in width, and 89 inches in height, along with a weight of 16,940 lbs, this machine is robust and built to last. The INTEGREX-100-IVST also includes a Royal auto chuck on both the main and secondary spindle, a thorough spindle coolant system, and chip conveyor for efficient operation.

If you have a 2013 Mazak INTEGREX-100-IVST or similar multi-tasking CNC lathe to sell, we want to hear from you! Contact us today to get a competitive offer and turn your unused machinery into cash.
