Make: G&L
Model: MAG VTC 1000
Year: 2009
Category: CNC Vertical Machining Centers (VMC)
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

G&L MAG VTC 1000 Specifications

# Axis: 2
Table Size: 40''
Maximum Swing: 51.18''
Maximum Facing Capacity: 51.18''
Rail Height: 66.14''
Spindle Speeds: 1-157 / 1-630 RPM
Spindle Torque: 18,250 Ft-Lbs
Table Horse Power: 112 HP
Auto Tool Changer: 18 ATC
Max Tool Length / Width: 27.55'' / 15.75''
Maximum Tool Weight: 253 LBS.
Tool Change Time: 18 SEC.
C Axis Travel: 360,000 Degree N/C
Z Axis Travel: 49.21''
Ram Size: 9.84'' x 9.84''
X Axis Travel: + X 33.07'' - X 14.57''
Rapid Traverse Rate X: 787 IPM
Rapid Traverse Rate Z: 787 IPM
Rotary Tool Horsepower: 44 HP
Rotary Tool Holder Type: Kennemetal KM80
Rotary Tool Holder Length / Width: 19.68'' / 7.09''
Maximum Rotary Tool Weight: 40 LBS.
Rotary Tool Spindle Speed: 4000 RPM
Machine Weight: 55,400 LBS.

Do you have a G&L MAG VTC 1000 to sell?

We are actively seeking a 2009 GIDDINGS & LEWIS MAG VTC 1000 Vertical 3-Axis CNC Machining Center. This exceptional machine, featuring a substantial table diameter of 40 inches and a maximum swing of 51.18 inches, is designed for precision and efficiency in machining applications. With a maximum facing capacity also reaching 51.18 inches, the MAG VTC 1000 is equipped to handle a wide range of projects, making it a valuable asset in any production environment. This model boasts impressive specifications, including spindle speeds ranging from 1 to 630 RPM and a robust spindle torque of 18,250 ft-lbs.

The 112 HP table horse power ensures that this machine can deliver the necessary power for demanding tasks. An auto tool changer with an 18 ATC capacity allows for seamless transitions between tools, enhancing productivity in your shop. The maximum tool length of 27.55 inches and width of 15.75 inches, along with a maximum tool weight of 253 lbs, offer versatility in machining different components. Rapid traverse speeds of 787 IPM in the X, Z, and Y axes contribute to the efficiency of this machine, while the C-axis spindle indexing capability of 360,000 degrees provides exceptional contouring.

With a Z-axis vertical ram travel of 49.21 inches and a ram size of 9.84 inches by 9.84 inches, the MAG VTC 1000 is built to handle various machining challenges with ease. Sellers often part with machines like the GIDDINGS & LEWIS MAG VTC 1000 for several reasons, including upgrading to newer technology, downsizing their operations, or even closing facilities altogether. If you're ready to sell your GIDDINGS & LEWIS MAG VTC 1000 or any other CNC Vertical Machining Center, we're here to assist you every step of the way. Contact us today to get started on selling your equipment with confidence.
