Direct procurement1971 Model

Sell your Fellows Gear Shaper Co P630 today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Fellows Gear Shaper Co
Model: P630
CNC Control: CNC (Fanuc 0iM-F Plus)
Year: 1971
Category: CNC Gear Machinery
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Fellows Gear Shaper Co P630 Specifications

Max Dia. Gear: 630 mm
Max Diametral Pitch: 2.51 dp
Horz/Vert: Vert
Axis: 5
Control: CNC (Fanuc 0iM-F Plus)
Dimensions L: 5980mm (235.4") W: 2915mm (114.8") H: 3430mm (135.0")
Weight: 18081lbs. (8200kg)
Number of CNC controlled axes: 4 - X,Y,Z,C
Number of Optional CNC controlled axes: 1 - A
Number of CNC controlled spindles: 1
Pitch rating: 2.54 DP 10 Mod
Maximum workpiece diameter: 24.803 in 630 mm
Maximum axial travel: 16.732 in 425 mm
Worktable diameter: 21.654 in 550 mm
Index worm diameter: 21.654 in 550 mm
Table bore diameter: 4.921 in 125 mm
Maximum radial center distance: 1.969 in 50 mm
Minimum axial height from table top: 5.709 in 145 mm
Maximum axial height from table top: 22.441 in 570 mm
Maximum hob diameter: 7.559 in 192 mm
Maximum hob length: 8.465 in 215 mm
Maximum hob shift travel: 7.874 in 200 mm
Minimum number of teeth: 6
Maximum swivel angle: -45 deg +45 deg
Hob speed range (Infinitely Variable): 62 to 390 RPM
Taper in hob spindle: Morse #5
Rapid traverse radial: 78.740 in 2000.000 mm/rev
Rapid traverse axial: 78.740 in 2000.000 mm/rev
Length: 235.433 in 5980 mm
Width: 114.764 in 2915 mm
Height: 135.039 in 3430 mm
Machine Weight: 18078 lbs 8200 kg
Plant power: 460 VAC 60 Hz
Controls: Fanuc 0iM-F Plus CNC. Fanuc Alpha HVi Drives and Motors
Base Software: Three passes (same or alternating directions). Hobbing of four sequential gears in one cycle. Inch / Metric switchable. Incremental shifting by part count. Crowning with high point offset capability. Taper compensation. Axial or radial/axial cycles. Radial only cycle. Programmable dwell. Automatic or manual overtravel and approach calculations. Simple single indexing cycle. Tool offsets for quick size changes. Workpiece counter. Multiple program storage and retrieval. Shifting with table compensation. Auxiliary function selection (tailstock/clamping seq.). Swing-away type tailstock with manual mechanical lever. Automatic or manual hob swivel angle calculation.

Do you have a Fellows Gear Shaper Co P630 to sell?

We are actively seeking a 1971 Fellows Gear Shaper Co P630 for our growing inventory of pre-owned cnc gear machinery equipment. Superior Machine Tools purchases CNC machinery directly from sellers across the United States, and Fellows Gear Shaper Co models like the P630 are exactly the kind of well-maintained equipment our buyers are looking for. Notable specifications include model of P630, year of 1971, category of CNC Gear Machinery, and max dia. gear of 630 mm. Selling a used Fellows Gear Shaper Co P630 doesn't have to be complicated.

We pay fair market value based on current demand for Fellows Gear Shaper Co cnc gear machinery equipment, and we close transactions quickly - often within days of an initial inquiry. There is no need to coordinate buyers, list on multiple marketplaces, or negotiate piecemeal. We make a single offer that reflects the current value of your machine. Once an offer is accepted, our logistics team handles the rest.

We arrange professional rigging and removal, manage all transportation, and ensure the Fellows Gear Shaper Co P630 is moved off your floor with minimal disruption to your operations. Whether you are upgrading to newer equipment, consolidating a facility, or liquidating an entire shop, we have the experience to make the process simple. If you have a 1971 Fellows Gear Shaper Co P630 you are considering selling, contact Superior Machine Tools today for a fast, no-obligation quote. We respond promptly, pay competitively, and remove the equipment on a timeline that works for you.
