Fanuc ROBODRILL ALPHA-D21SIA5 USED (2013)

Direct procurement2013 Model

Sell your Fanuc ROBODRILL ALPHA-D21SIA5 USED today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Fanuc
Model: ROBODRILL ALPHA-D21SIA5 USED
Year: 2013
Category: CNC Drilling & Tapping Centers
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Fanuc ROBODRILL ALPHA-D21SIA5 USED Specifications

X - Axis: 11.8" 299.72 mm
Y - Axis: 11.8" 299.72 mm
Z - Axis: 13" 330.2 mm
Power: 15 hp 11.2 kW
RPM: 24,000 RPM
# ATC: 21
Axis Travel: 300mm (X Axis), 400mm (Y Axis), 330mm (Z
Table Area: 630mm x 330mm With A 200 kg Load Capacity
Spindle Taper: BT-30
Tool Changer: 21 Position, Bi-Directional
Tool Change Time: 1.6 Second (Chip to Chip), 0.9 Second (Tool to Tool)
Duty Cycle Time: 5,000,000
Rigid Tapping: up to 8,000 RPM
Servo Response Time: 1 Millisecond
Rapid Rate: 2125 IPM X, Y, Z Axis
Feed Rates: up to 1181 IPM X, Y, Z
Acceleration: 1.5 G
Memory: 2 MB
Registerable Programs: 1,000
Tool Offset Pairs: 200 Pairs
Part Program Storage: 2 MB
Work Offsets: 6 + 48
Coolant System: 200 liter coolant tank Nozzle
Tool Compensation Memory: C
Coordinate System Rotation: (G68.G69)
Coordinate System Setting: (G92)
Canned cycles for drilling: (G73, G74, G81~G89/G80)
Other: Manual Handle Feed
Other: Dynamic Graphic Display
Other: On Screen Display of Spindle ‘ RPM’ and ‘Load’ Meters
Other: Alpha Numeric Keyboard
Other: Automatic Lubrication System.

Do you have a Fanuc ROBODRILL ALPHA-D21SIA5 USED to sell?

We are actively seeking a 2013 FANUC ROBODRILL ALPHA-D21SIA5, a highly efficient vertical machining center known for its precision in drilling and tapping applications. This machine boasts a powerful 7.5 hp motor and a maximum spindle speed of 10,000 RPM, ensuring rapid and accurate machining capabilities. The 21-position bi-directional tool changer allows for seamless transitions between tools, with a remarkable tool change time of just 1.6 seconds chip-to-chip and 0.9 seconds tool-to-tool, which significantly enhances productivity on the shop floor. With dimensions of 50 inches by 79 inches by 87 inches and a weight of 4,409 lbs, the ROBODRILL ALPHA-D21SIA5 is compact yet robust.

It features a table area of 630mm x 330mm, supporting a load capacity of up to 200 kg, making it ideal for a variety of machining tasks. The machine is equipped with a coolant system featuring a 200-liter tank, which is essential for maintaining optimal cutting conditions and prolonging tool life. Its rapid rate of 2125 IPM in the X, Y, and Z axes and feed rates of up to 1181 IPM provide exceptional speed and efficiency, while the servo response time of only 1 millisecond ensures high accuracy in machining operations. With a duty cycle time of 5,000,000 and rigid tapping capabilities of up to 8,000 RPM, this machine is built for durability and performance.

If you have a 2013 FANUC ROBODRILL ALPHA-D21SIA5 or similar equipment you're looking to sell, we invite you to contact us. At Superior Machine Tools, we specialize in purchasing used CNC machines, and we offer competitive prices to ensure you get the best value for your equipment. Don't miss this opportunity to turn your unused machinery into cash today!
