Direct procurement2022 Model

Sell your Doosan GT2600M today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Doosan
Model: GT2600M
Year: 2022
Category: CNC Lathes
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Doosan GT2600M Specifications

Swing Over Bed: 24.8"
Turning Diameter: 16.1"
Machining Length: 25.9"
Distance Between Centers: 27"
Chuck Size: 10"
Spindle Nose: A2 - 8"
Spindle Bore Diameter: 3.9"
Spindle Bar Capacity: 3.2"
Spindle Speeds: 3500 RPM
Spindle Horsepower: 30 HP
Spindle Torque: 459 FT. - LBS.
X - Axis Travel: 10.4"
Z - Axis Travel: 26.8"
C - Axis Travel: .001 DEGREE
Rapid Traverse Rates X: 945 IPM
Rapid Traverse Rates Z: 1181 IPM
Rapid Traverse C Axis: 220 RPM
Turret Configuration: 12
Turret Rotary Tool Spindle Speed: 5,000 RPM
Turret Rotary Tool Horse Power: 7.4 HP
Tailstock Quill Diameter: 3.9"
Tailstock Taper: MT 5
Tailstock Quill Travel: 3.9"
Programmable Tailstock: YES
Tailstock Travel: 26.8"
Machine Weight: 9591 LBS.

Do you have a Doosan GT2600M to sell?

We are actively seeking a 2022 DOOSAN GT2600M 2-Axis CNC Lathe. This high-performance lathe is designed to meet the rigorous demands of modern machining with precision and efficiency. With a swing over bed of 24.8 inches and a turning diameter of 16.1 inches, the GT2600M is capable of handling a variety of workpieces. The machining length of 25.9 inches and a distance between centers of 27 inches allows for significant versatility, making it an ideal choice for both small and large production runs.

Equipped with a robust 10-inch chuck and an A2-8 spindle nose, this machine features a spindle bore diameter of 3.9 inches and a spindle bar capacity of 3.2 inches. With spindle speeds reaching up to 3500 RPM and spindle horsepower of 30, the GT2600M delivers the power needed for demanding applications. The spindle torque of 459 ft-lbs ensures reliable performance, even under heavy loads. Additionally, the X-axis travel of 10.4 inches and Z-axis travel of 26.8 inches provide ample space for complex machining tasks.

The GT2600M also boasts rapid traverse rates of 945 IPM in the X-axis and 1181 IPM in the Z-axis, along with a C-axis travel resolution of .001 degrees, which significantly enhances productivity. Its 12-station turret configuration allows for quick tool changes, while the turret rotary tool spindle speed of 5,000 RPM and horsepower of 7.4 HP enable efficient multi-tasking. Sellers often consider parting with machines like the DOOSAN GT2600M for various reasons, including upgrading to newer technology, downsizing operations, or even complete plant closures. If you're ready to sell your 2022 DOOSAN GT2600M or any other used CNC equipment, contact us today to discuss a seamless selling experience.
