Sell your Mazak MULTIPLEX-6200-II 2016 today.
Mazak MULTIPLEX-6200-II Specifications
| Chuck Diameter | 8" |
|---|---|
| Maximum Swing | 12.5" |
| Maximum Cutting Diameter | 10.24" |
| Maximum Bar Diameter | 2.5" |
| Maximum Chuckwork Machining Length | 7.0" |
| Maximum Shaftwork Machining Length | 21.0" |
| Distance Between Spindle Faces | Max: 46.85" |
| Min | 10.15" |
| Spindle Nose | A2-6 |
| Spindle Bore Diameter | 2.4" |
| Maximum Spindle Speed | 5,000 RPM |
| Spindle Indexing (C Axis) | .001 deg./360,000 Positions |
| Continuous Spindle Horsepower | 20 HP |
| Spindle Torque | 258.2 ft.-lbs. |
| Number of Tool Turrets | 1 |
| Turret Index Time | 0.2 sec. |
| Total Tool Capacity | 24 |
| Maximum Tool Size (Turning & Facing) | 1" x 1" |
| Maximum Boring Bar Diameter | 1-1/2" |
| X Axis Travel | 9.06" |
| Z Axis Travel (L) | 17.25" |
| Z Axis Travel (R) | 19.37" |
| X Axis Rapid Traverse Rate | 1200 IPM |
| Z Axis Rapid Traverse Rate | 1300 IPM |
| C Axis Rapid Traverse Rate | 400 RPM |
| Machine Floor Space | 71.9" x 140.6" |
| Machine Height | 82.3" |
| Total Power Required | 77.4 KVA |
| Air Requirements | 71 PSI / 14 CFM |
| Total Machine Weight | 17,380 lbs. |
| Control System | MAZATROL MATRIX 2 |
| Screen Size | 15" |
| Interface | USB, LAN, IC Memory Card |
| Tool Eye | Automatic, Left & Right |
| Automatic Chuck Jaws | Open/Close, Left & Right |
| Other | Equipped with SYNCHRONIZED Z-AXIS, USER MACRO (COMMON VARIABLES: 600 PAIRS), EIA/ISO CODE INPUT FUNCTION (STANDARD), SEQUENCE NUMBER COMPARISON STOP FUNCTION, BACKGROUND TOOL PATH CHECK, INCH/METRIC CONVERSION, POLAR COORDINATES INPUT (G122) (EIA), B)CYLINDRICAL (G07) & POLAR COORDINATE (G12) (EIA), INTELLIGENT THERMAL SHIELD, AUTOMATIC WORKPIECE TRANSFER, ABSOLUTE POSITIONING SYS (N/A WITH S/F) |
Do you have a Mazak MULTIPLEX-6200-II to sell?
We are actively seeking a 2016 Mazak MULTIPLEX-6200-II CNC Multi-Tasking Machine. This exceptional machine features a twin spindle and twin turret design, providing remarkable versatility for various machining tasks. With a maximum swing of 12.5 inches and a standard chuck diameter of 8 inches, it is perfectly suited for both turning and milling operations. The maximum bar diameter of 2.5 inches allows for efficient processing of a wide range of materials. Equipped with a robust spindle that offers a speed range of 35 to 5,000 RPM, this machine boasts a spindle horsepower of 20 HP for continuous use and 30 HP for short-term applications. The spindle torque of 258.2 ft-lbs ensures that it can handle demanding tasks with ease.
The MULTIPLEX-6200-II is designed with productivity in mind, featuring a rapid traverse rate of 1,200 IPM on the X-axis and 1,300 IPM on the Z-axis. Its synchronized Z-axis enhances precision during machining. The machine's turret index time is an impressive 0.2 seconds, which allows for quick tool changes and minimal downtime. With a total of 24 tool positions, this machine can accommodate various cutting tools, making it ideal for job shops and manufacturing environments. Many sellers find themselves parting with machines like the MULTIPLEX-6200-II for various reasons, including upgrading to newer models, downsizing their operations, or closing facilities altogether. Whatever the reason, we understand that selling your CNC machine can be a significant decision.
We aim to make the process as smooth and straightforward as possible. At Superior Machine Tools, we buy CNC machines nationwide and are committed to offering fast payments and hassle-free logistics. Our team is ready to assist you with every step of the selling process, ensuring you receive a fair price for your equipment. If you own a 2016 Mazak MULTIPLEX-6200-II or a similar model, don't hesitate to reach out to us for a no-obligation quote. Let us help you turn your unused equipment into cash quickly and easily.
