Sell your Mazak hyper quadrex 200msy matrix 2011 today.
Mazak hyper quadrex 200msy matrix Specifications
| Maximum Swing Over Upper Turret | 14.56" |
|---|---|
| Maximum Swing Over Lower Turret | 12.598" |
| Maximum Machining Diameter | Chucking: 13.54" (Upper) |
| Maximum Machining Diameter | Chucking: 8.26" (Lower) |
| Maximum Distance Between Chuck Jaws | 33.875" |
| Spindle Nose | A2-6 |
| Spindle Bore | 2.99" |
| Maximum Bar Work | 2.56" |
| Spindle Speed | 35-5,000 RPM |
| Spindle Index (Programmable) | 0.0001 Deg. 3,600,000 Positions |
| Spindle Horsepower (Cont./30 Min.) | 20/30 HP (AC) |
| Spindle Torque (25% ED) | 344.4 ft-lbs. |
| Type of Turret | 12 pos. Drum VDI Rotary |
| Tool Spindle Speed | 35-6,000 RPM |
| Rotary Tool Spindle Horsepower/(10 min) | 7.5 HP |
| X1-Axis | 8.2" |
| Y1-Axis | +/-2.0" |
| Z1-Axis | 29.875" |
| X2-Axis.Lower | 5.5625" |
| Y2 Axis Lower | +0.75"/-2.0" |
| Z2 Axis Lower | 32.125" |
| W Axis | 34.075" |
Do you have a Mazak hyper quadrex 200msy matrix to sell?
We are actively seeking a 2011 Mazak Hyper Quadrex 200MSY (Matrix), a premier multi-tasking CNC lathe that exemplifies advanced machining capabilities. This machine boasts a maximum swing over the upper turret of 14.56 inches and 12.598 inches over the lower turret, allowing for a versatile range of applications in complex machining tasks. With a maximum machining diameter for chucking of 13.54 inches on the upper side and 8.26 inches on the lower side, this lathe is designed to handle a variety of materials with precision and ease. The Hyper Quadrex 200MSY features a spindle nose of A2-6 and a spindle bore of 2.99 inches, ensuring robust performance under demanding conditions.
Its impressive spindle speed range of 35 to 5,000 RPM provides the flexibility needed for both high-speed and heavy-duty operations. The programmable spindle indexing capability allows for precise positioning with an accuracy of 0.0001 degrees, offering 3,600,000 positions for enhanced precision. This model is equipped with a 12-position drum VDI rotary turret, which enables quick tool changes and maximizes productivity. The tool spindle speed can reach up to 6,000 RPM, powered by a 7.5 HP motor, making it suitable for a broad range of tooling operations.
The X1 and Z1 axes travel up to 8.2 inches and 29.875 inches, respectively, while the lower turret axes provide additional versatility with their own travel ranges. If you have a 2011 Mazak Hyper Quadrex 200MSY (Matrix) that you are looking to sell, we at Superior Machine Tools are here to help. We specialize in purchasing used CNC machines and offer competitive prices to ensure you get the best value for your equipment. Contact us today to discuss your machine and how we can assist you in the selling process.
