Sell your Mazak HYPER-QUADREX-200MSY 2011 today.
Mazak HYPER-QUADREX-200MSY Specifications
| Chuck Size | 8" |
|---|---|
| W Axis | 34.075" |
| Max Bar Capacity | 2.56" |
| Spindle Horsepower (Cont./30 Min.) | 20/30 HP |
| X1-Axis Travel | 8.2" |
| Spindle Power | 20/30 HP |
| Swing Over Carriage | 14.56" |
| X-Axis (Cross Travel) | 8.2" |
| Z-Axis (Longitudinal Travel) | 29.875" |
| Y-Axis | +/-2.0" |
| Tailstock Quill Taper | A6-S26 |
| Spindle Speeds 1, 2 | 35-5,000 RPM |
| Spindle Nose | A2-6 |
| Turret Positions | 12 pos. Drum VDI |
| Spindle Bore Diameter | 2.99" |
| Spindle Speed | 35-5,000 RPM |
| Chuck Size 1, 2 | 8" |
| High Pressure Coolant System | Yes |
| Automatic Tool Eye | Yes |
| Collet Chuck | Royal Accu-Length A6-S26 |
| Operating System | Windows XP |
| Main Spindle Bore | 2.99" |
| Rotary Tool Spindle Horsepower/(10 Min) | 7.5 HP |
| Chuck Size (2Nd Spindle) | 8" |
| X2-Axis (Lower) | 5.5625" |
| Spindle Torque (25% Ed) | 344.4 ft-lbs |
| Chuck Size (Main) | 8" |
| Y1-Axis | +/-2.0" |
| Barfeed | LNS Quick Load Servo 80-S2 Short Magazine |
| Z2 Axis Lower | 32.125" |
| W - Axis Travel Sub Spindle | 34.075" |
| Spindle Bore Diameter 1, 2 | 2.99" |
| Spindle Nose 1 | A2-6 |
| Maximum Machining Diameter (Lower) | 8.26" |
| Maximum Swing Over Lower Turret | 12.598" |
| Other | Max. |
Do you have a Mazak HYPER-QUADREX-200MSY to sell?
We are actively seeking a 2011 Mazak Hyper-Quadrex-200MSY, a state-of-the-art multi-tasking CNC turning center that combines precision and versatility. This machine is designed for high-performance machining and is equipped with the advanced Mazatrol Matrix Control system, allowing for intuitive programming and operation. With a maximum swing over the upper turret of 14.56 inches and the lower turret of 12.598 inches, it accommodates a variety of workpieces, making it an ideal choice for diverse manufacturing needs. The Hyper-Quadrex-200MSY boasts an impressive spindle speed range of 35 to 5,000 RPM, paired with a spindle horsepower of 20/30 HP (AC), ensuring efficient material removal and superior surface finishes.
Its maximum machining diameter for the upper turret reaches 13.54 inches, while the lower turret can handle up to 8.26 inches, providing flexibility in production. The machine's robust spindle torque of 344.4 ft-lbs at 25% ED enhances its ability to perform complex machining tasks with ease. This model comes equipped with a variety of features including a 12-position drum VDI turret, a high-pressure coolant system, and an automatic tool eye for precision tool setup. The capacity to work with a bar of up to 2.56 inches and a chuck size of 8 inches on the second spindle further expands its capabilities.
The integrated LNS Quick Load Servo 80-S2 short magazine bar feed system optimizes productivity, while the side disposal chip conveyor streamlines maintenance. If you have a Mazak Hyper-Quadrex-200MSY you're looking to sell, now is the perfect time to reach out. At Superior Machine Tools, we offer competitive prices and a hassle-free selling experience. Contact us today to get a quote and turn your unused machinery into cash!
