2017 Makino A61NX-5E
Used · CNC Horizontal Boring Mills (HBM)
Spindle power
80 hp
CNC 5-Axis Machining Centers
Makino A61NX-5E
7 Makino A61NX-5E listings have come through the used market we track on 4 marketplaces, built from 2014 to 2017 where the listing gave a year. Listings that repeat the same machine are shown once, as 6 machines.
28.7 inX-axis travel
26.8 inZ-axis travel
28.7 inY-axis travel
24,000 RPMSpindle speed
What the maker publishes about the current Makino A61NX-5E
Makino describes the a61nx-5E as a five-axis horizontal machining center for aluminum parts of small to mid size, aerospace work in particular. It sits on a 400 mm by 400 mm pallet with strokes of 730 mm in X, 730 mm in Y and 680 mm in Z. Two direct drive rotary axes supply the extra motion: B swivels 290 degrees, from -110 to +180, and C turns a full 360. The pallet changer loads the pallet directly into the rotary table. A 14,000 rpm spindle is standard and a 24,000 rpm spindle is optional. Rapid traverse is 48 m/min in X and Y and 43 m/min in Z. The largest workpiece is ø700 mm by 400 mm, with limitations, and payload tops out at 150 kg. The magazine holds 60 tools, with 133, 218 or 313 optional. Tools can be 170 mm across and 12 kg.
Source: Makino, October 14, 2026.
Makino A61NX-5E specifications
Manufacturer specification. Every figure below was read from the manufacturer’s own published specification for this machine and checked back against that document word for word.
These are the manufacturer’s figures for this model as currently published. A machine built years ago may differ in control generation and in options, which is exactly why the questions below matter when you sell one.
Capacity and travels
X-axis travelX: 730 mm Y: 730 mm Z: 680 mm
730 mm
Y-axis travelX: 730 mm Y: 730 mm Z: 680 mm
730 mm
Z-axis travelX: 730 mm Y: 730 mm Z: 680 mm
680 mm
AxesHorizontal Machining 5-Axis
5-Axis
Spindle and speed
Max spindle speedSpindle RPM
14,000 rpm
Rapid traverseRapid Traverse
X, Y: 48 m/min | Z: 43 m/min
Table, turret and tools
Max table loadMaximum Payload
150 kg
Pallet sizePallet:
400 × 400 mm
Tool capacityATC Capacity
60 tools
Further figures the manufacturer publishes
B-Axis
290° (-110° ~ +180°) Direct Drive
C-Axis
360° Direct Drive
Maximum Workpiece
Ø700 × 400 mm (with limitations)
Maximum Tool Diameter
170 mm
Maximum Tool Weight
12 kg
Option: Spindle RPM
24,000 rpm
Option: ATC Capacity
133 / 218 / 313 tools
- manufacturer specification page, fetched September 16, 2026.
What fits a Makino A61NX-5E
Each of these follows from a published specification above, which is named beside it.
Pallets and fixturing
Fixtures, tombstones and spare pallets are cut for a pallet of this size and do not transfer to another machine. On a horizontal they are a large share of what is being sold, so count them before quoting.
Derived from Pallet size: 400 × 400 mm
What to check on a Makino A61NX-5E
- Spindle. The manufacturer gives a spindle speed of 14,000 rpm. Run the spindle to top speed and listen for bearing noise.
- Axes and way covers. The manufacturer gives X 730 mm, Y 730 mm and Z 680 mm of travel. Run each axis end to end and check the way covers.
- Tool changer. The manufacturer gives the tool capacity as 60 tools. Cycle every pocket and watch for a hesitation.
- Pallet changer. The manufacturer gives a pallet size of 400 × 400 mm. Run a full pallet change, and count the pallets and fixtures that come with the machine.
Makino A61NX-5E listing history
Where it was listed
equipt.com
3 listings, model years 2014 to 2017
machinetools.com
2 listings, model year 2016
machnet.com
1 listing, model year 2017
surplusrecord.com
1 listing, model year 2016
Sellers also filed it under CNC Horizontal Boring Mills (HBM) (2 listings) and CNC Horizontal Machining Centers (HMC) (2 listings).
Model years seen
2017 (2 units), 2016 (2 units), 2014 (2 units).
What Makino A61NX-5E listings agree on
X-axis travel
28.7 in
Y-axis travel
28.7 in
Z-axis travel
26.8 in
Spindle speed
24,000 RPM
Spindle power
80 hp (2 machines); 107 hp (2 machines)
Spindle taper
HSK-A63
Tool capacity
60
Every Makino A61NX-5E we have tracked
2017 Makino A61NX-5E
Used · CNC 5-Axis Machining Centers
Spindle power
107 hp
2016 Makino A61NX-5E
Used · CNC Horizontal Machining Centers (HMC)
Spindle power
80 hp
2016 Makino A61NX-5E
Used · CNC Horizontal Machining Centers (HMC)
2014 Makino A61NX-5E
Used · CNC Horizontal Boring Mills (HBM) · Listed 2 times (equipt.com)
Spindle power
107 hp
1 more listing gave no year.
The Makino A61NX-5E among machining centers and mills
Browse all CNC 5-Axis Machining Centers, or see every Makino machine we track.
Makino A61NX-5E variants and related models
Makino A61NX
Variant
Makino A51NX
Same series
- X-axis travel
- 560 mm1this model: 730 mm2
- Y-axis travel
- 640 mm1this model: 730 mm2
Makino A81NX
Same series
- X-axis travel
- 900 mm3this model: 730 mm2
- Max spindle speed
- 10,000 (8,000 High Torque opt)3this model: 14,000 rpm2
- Makino A51NX: manufacturer specification page, fetched October 14, 2026.
- Makino A61NX-5E: manufacturer specification page, fetched September 16, 2026.
- Makino A81NX: manufacturer specification page, fetched September 16, 2026.
