Haas ST-35 USED Specifications
| Swing | 31.75" 806.45 mm |
|---|---|
| Machining Length | 26" 660.4 mm |
| Chuck Size | 15.0 in 380 mm |
| Bar Capacity | 4.00 in 102 mm |
| Power | 40.0 hp 29.8 kW |
| Max RPM | 3200 rpm |
| Turning Dia | 21.0 in 533.4 mm |
| Tailstock | Yes |
| X Travel | 9.40 in 239 mm |
| Z Travel | 32.50 in 826 mm |
| Dimensions | 171.0 in x 90.0 in x 92.0 in 435 cm x 229 cm x 234 cm |
| Weight | 14300 lb 6487.0 kg |
| Max Part Swing | 21.0 in 533 mm |
| Max Cutting Diameter (with BOT turret) | 15.00 in 381 mm |
| Max Cutting Diameter (with BMT65 turret) | 13.75 in 349 mm |
| Max Cutting Length (varies with workholding) | 32.5 in 826 mm |
| Rapids on X | 945 ipm 24.0 m/min |
| Rapids on Z | 945 ipm 24.0 m/min |
| Max Thrust X | 4100 lbf 18238 N |
| Max Thrust Z | 5100 lbf 22686 N |
| Spindle Nose | A2-8 A2-8 |
| Max Rating | 40.0 hp 29.8 kW |
| Max Torque | 425.0 ft-lbf @ 325 rpm 576.0 Nm @ 325 rpm |
| Max Torque w/opt Gearbox | 1400 ft-lbf @ 150 rpm 1898 Nm @ 150 rpm |
| Spindle Bore ø | 4.62 in 117.3 mm |
| Max Sync Speed w/Main Spindle | 4100 rpm |
| Chuck Throat Ø | 1.81 in x 1.60 in DEEP 46.0 mm x 40.6 mm DEEP |
| Drawbar Adapter Bore Ø | 1.81 in x 3.09 in DEEP 46.0 mm x 78.5 mm DEEP |
| Drawbar Bore (non-through) Ø | 1.03 in x 4.91 in DEEP 26.2 mm x 124.7 mm DEEP |
| Spindle Bore (without chuck and drawbar installed) | 2.31 in 58.7 mm |
| Integrated Brake Torque | 17 ft-lbf 23 N/m |
| Spindle Orientation Accuracy (Requires SO) | ± 0.02 ° ± 0.02 ° |
| Number of Tools | 12-Station BOT |
| Coolant Capacity | 55 gal 208 L |
| Air Required | 4 scfm @ 100 psi 113 L/min @ 6.9 bar |
| Inline Air Hose | 3/8 in |
| Coupler (Air) | 3/8 in |
| Air Pressure Min | 80 psi 5.5 bar |
| Spindle Speed | 3200 rpm |
| Drive System | Direct Speed, Belt Drive |
| Spindle Power | 40.0 hp 29.8 kW |
| Input AC Voltage (3 Phase) - Low | 220 VAC |
| Full Load Amps (3 Phase) - Low | 70 A |
| Input AC Voltage (3 Phase) - High* | 440 VAC |
| Full Load Amps (3 Phase) - High* | 35 A. |
Do you have a Haas ST-35 USED to sell?
We are actively seeking a 2014 Haas ST-35 CNC Lathe, a robust horizontal turning center known for its precision and performance. This machine is equipped with a 15-inch 3-jaw chuck and offers an impressive swing of 31.75 inches, making it suitable for a variety of machining applications. With a machining length of 26 inches and a bar capacity of 4 inches, the Haas ST-35 is designed to handle substantial workpieces with ease. Its powerful 40 hp spindle can reach a maximum speed of 3,200 RPM, ensuring efficient and high-quality cuts.
The lathe features an X travel of 9.4 inches and a Z travel of 32.5 inches, allowing for versatile machining operations. The machine's rapid traverse rates of 945 inches per minute on both the X and Z axes further enhance its productivity. Weighing in at 14,300 lbs, this CNC lathe is built for stability and durability, which is crucial for precision work. The spindle bore measures 4.62 inches, providing ample room for larger components.
Additionally, the Haas ST-35 includes a tailstock for increased support during machining, making it an excellent choice for complex tasks. Its dimensions of 171 x 90 x 92 inches make it a substantial addition to any workshop. If you're looking to sell your 2014 Haas ST-35 or any other used CNC machines, we offer competitive pricing and a hassle-free selling experience. Contact us today to get a quote and turn your idle machinery into cash!
