Sell your Gleason 102 today.
Gleason 102 Specifications
| Diametral Pitch (Coarsest) | 16 DP |
|---|---|
| Cone Distance | 0” – 2 5/16” 0 – 59mm |
| Workhead Angle | -12 deg. To 90 deg |
| Minimum Ratio for Non-Generated Spiral Bevel Gears | 2.5 to 1 |
| Minimum Ratio for Non-Generated Hypoid Gears | 3.5 to 1 |
| Maximum Gear Pitch Diameter | Not specified |
| Face Width (Maximum) | 7/14” 11mm |
| Number of Teeth | 5-200 |
| Diameter of Taper Bore, Large End | 1 17/32” |
| Taper | ½” /ft |
| Depth of Taper | 3” |
| Diameter of Hole Through Spindle | ¾” |
| Cutter Diameter | 1.1”, 1.5”, 2”, 2.75” 3.5” 28mm, 38mm, 51mm, 70mm, 89mm |
| Maximum Offset Above Centre | 1” 29mm |
| Maximum Offset Below Centre | 1” 29mm |
| Max Distance from Machine Centre to Nose of Spindle | 5.0” 127mm |
| Min Distance from Machine Centre to Nose of Spindle | 1 ¼” 32mm |
Do you have a Gleason 102 to sell?
We are actively seeking a 6092 Gleason 102 CNC Gear Shaping machine. This exceptional piece of equipment is renowned for its precision in generating spiral bevel gears. The Gleason 102 boasts a coarsest diametral pitch of 16 DP, making it ideal for a variety of gear manufacturing applications. With a cone distance range of 0" to 2 5/16" (0 – 59mm), it provides versatility in gear production. The workhead angle can be adjusted from -12 degrees to 90 degrees, allowing for intricate machining capabilities.
This machine is particularly suitable for creating non-generated spiral bevel gears with a minimum ratio of 2.5 to 1 and hypoid gears with a minimum ratio of 3.5 to 1, ensuring it meets a wide range of manufacturing requirements. The maximum face width is an impressive 7/14" (11mm), and it can accommodate between 5 to 200 teeth, which gives manufacturers the flexibility to produce a diverse array of gears. The Gleason 102 is equipped with a taper bore measuring 1 17/32" at the large end, with a taper of ½" per foot and a depth of taper of 3". The spindle features a hole diameter of ¾", which is suitable for various cutting tools. Cutter diameters range from 1.1" to 3.5" (28mm to 89mm), further enhancing its versatility.
Additionally, it offers maximum offset capabilities above and below the center of 1" (29mm), allowing for precise adjustments during operation. If you have a 6092 Gleason 102 CNC Gear Shaping machine that you are looking to sell, we at Superior Machine Tools are interested in purchasing it. Our team is dedicated to providing you with a fair valuation and a seamless transaction process. Contact us today to discuss your machine and see how we can assist you!
