Sell your Chevalier FSG-1640ADIII Year 2014 today.
Chevalier FSG-1640ADIII Year Specifications
| Capacity | 16" x 40" (400 x 1000mm) Table |
|---|---|
| Max Grinding Length | 40" (1015mm) |
| Max Grinding Width | 16" (405mm) |
| Max Distance (Table to Spindle Center) | 24.4" (620mm) |
| Spindle Motor | 5 HP / 4P (Optional 10 HP available) |
| Spindle Speed | 1750 rpm (60Hz) |
| Grinding Wheel | 14" x 2" x 5" (355 x 50 x 127mm) |
| Weight | Approx. 3500 kg (8,000 lbs) |
| Dimensions | Approx. 168" x 68" x 81" (4280 x 1730 x 2080mm) |
| Longitudinal Table Travel (Hydraulic) | 1050mm (approx. 41.3") |
| Cross Feed (Automatic) | 405mm (approx. 16") |
| Vertical Feed (Automatic) | 480mm (approx. 18.9") |
| Longitudinal Table Speed | 5-25 m/min (infinitely variable) |
| Rapid Vertical Feed | 500mm/min |
| Minimum Downfeed Increment | 0.001mm (0.00005") |
| Controller | User-friendly touch-screen CNC (iSurface) |
| Vertical Drive | AC Servo motor |
| Typical Standard Equipment | Hydraulic system, Over-the-wheel dresser, Electromagnetic chuck and controller, Coolant system with double filter |
Do you have a Chevalier FSG-1640ADIII Year to sell?
We are actively seeking a 2014 Chevalier FSG-1640ADIII, a robust CNC hydraulic surface grinder known for its precision and efficiency. This model boasts a table capacity of 16" x 40" (400 x 1000mm) and can handle a maximum grinding length of 40" (1015mm) and a maximum grinding width of 16" (405mm). With a spindle motor rated at 5 HP, the FSG-1640ADIII operates at a spindle speed of 1750 RPM, making it ideal for various grinding applications. The machine's generous maximum distance from the table to spindle center is 24.4" (620mm), providing ample clearance for larger workpieces.
One of the standout features of the FSG-1640ADIII is its user-friendly touch-screen CNC controller (iSurface), which simplifies operation and enhances user experience. The machine is equipped with an electromagnetic chuck that ensures a firm grip on the workpiece during grinding, along with an over-the-wheel dresser for precise wheel shaping. The hydraulic system enables smooth longitudinal table travel of up to 1050mm (approx. 41.3"), while the automatic cross feed reaches 405mm (approx. 16"), and the vertical feed allows for 480mm (approx. 18.9") of adjustment. For high productivity, the longitudinal table speed is infinitely variable from 5-25 m/min, and it features a rapid vertical feed rate of 500mm/min, along with a minimum downfeed increment of 0.001mm (0.00005").
With an approximate weight of 3500 kg (8,000 lbs) and overall dimensions of 168" x 68" x 81" (4280 x 1730 x 2080mm), the Chevalier FSG-1640ADIII is a substantial machine that can fit into various shop environments. If you have this machine or any similar equipment to sell, we invite you to contact us today to discuss a fair and competitive offer. Let us help you maximize your investment!
