Sell your Bourn & Koch 14-15 USED 1998 today.
Bourn & Koch 14-15 USED Specifications
| Max Diametral Pitch in Steel | 3.5 dp |
|---|---|
| Max Rated Work Diameter | 14" (355.6 mm) |
| Max Travel of Hob Slide | 15" (381 mm) |
| Max Distance Work Spindle Face to Tail Center | 27.25" (692.15 mm) |
| Max Distance Work Spindle Centerline to Hob Spindle | 9.75" (247.65 mm) |
| Min Distance Work Spindle Centerline to Hob Spindle | 1.75" (44.45 mm) |
| Work Spindle Bore (Standard) | 4.18" (106.17 mm) |
| Index Worm Gear Pitch Diameter | 17.9" (454.66 mm) |
| Max Number of Teeth Cut | 300 |
| Min Number of Teeth Cut | 4 |
| Max Hob Diameter (Standard) | 6.25" (158.75 mm) |
| Max Swivel Angle (Helix) Setting R/L | 50° |
| Max Hob Shift Travel | 4" (101.6 mm) |
| Main Drive Power | 10 hp (7.5 kW) |
| Hydraulic Pump Power | 3 hp (2.2 kW) |
| Lubricating Pump Power | 0.2 hp (0.2 kW) |
| Coolant Pump Power | 1 hp (0.7 kW) |
| Dimensions | 114" x 81" x 90" |
| Weight | 13,000 LBS |
Do you have a Bourn & Koch 14-15 USED to sell?
We are actively seeking a 1998 Bourn & Koch 14-15 Gear Hobber to purchase for our inventory. This heavy-duty horizontal gear hobber is known for its precision and reliability, making it an excellent choice for any machining operation. With a maximum work diameter of 14 inches and a hob slide travel of 15 inches, this model is designed to handle a variety of gear cutting tasks with ease. The 6.25-inch maximum hob diameter allows for versatility in cutting different sizes of gears, while the auto hob shift and auto 2-cut cycle features enhance operational efficiency.
This particular machine boasts a maximum diametral pitch in steel of 3.5 dp, accommodating a wide range of gear specifications. The work spindle face to tail center distance of 27.25 inches and the adjustable distance from the work spindle centerline to hob spindle (ranging from 1.75 to 9.75 inches) provide the flexibility needed for various applications. Additionally, the Bourn & Koch 14-15 can cut between 4 and 300 teeth, making it suitable for both small and large production runs. With a main drive power of 10 hp and a hydraulic pump power of 3 hp, this machine is built for robust performance.
The compact dimensions of 114 inches in length, 81 inches in width, and 90 inches in height, combined with a weight of 13,000 lbs, ensure stability during operation. If you have a 1998 Bourn & Koch 14-15 Gear Hobber that you are looking to sell, we would love to hear from you. At Superior Machine Tools, we specialize in buying used CNC machines and offer competitive prices. Contact us today to discuss your machine and receive a fair offer.
