Direct procurement1974 Model

Sell your Pfauter-Maag SH-250 Year today.

MTE does not act as a broker, nor do we buy on consignment. We buy machinery and assets outright and arrange the pickup.

Make: Pfauter-Maag
Model: SH-250 Year
Year: 1974
Category: CNC Gear Machinery
Condition: Used / Surplus

Jason PuuriOwner, Superior Machine & Tool, Inc.Message From MTE Owner

Jason sets final pricing on the machines MTE buys.

Pfauter-Maag SH-250 Year Specifications

Max. Tip Circle Dia. (Spur Gear): 98.4"
Min. Tip Circle Dia. (Spur Gear): 7.9"
Module Min Pitch w/ Rack-Type Cutter: 0.0875 DP
Module Max Pitch w/ Rack-Type Cutter: 12.7 DP
Module Max w/ Single-Tooth Cutter: 0.5 DP
Min./ Max. Number of Teeth: 12/1000
Helix Angle: Infinite
Max. Face Width (Spur Gear): 26"
Max. Table Load: 33000 lbs.
Max. Ram Stroke: 27"
Min. Ram Stroke: 2.75"
Diameter of Work Table Bore: 16.5"
Work Table Bore Length: 47.2"
Machine Footprint (L X W): 235" x 169"
Machine Height: 131"
Machine Weight: 84,000 lbs.

Do you have a Pfauter-Maag SH-250 Year to sell?

We are actively seeking a 1974 Maag SH-250 Gear Shaper, a reliable piece of CNC gear machinery known for its robust specifications and performance. This model features an impressive maximum tip circle diameter of 98.4 inches, making it ideal for a wide range of gear shaping applications. With a minimum tip circle diameter of 7.9 inches, it allows for versatility in production. The machine accommodates a module max pitch of 0.5 DP with a single-tooth cutter, and it can work with a minimum pitch of 0.0875 DP when using a rack-type cutter.

The infinite helix angle capability enhances its flexibility, enabling the production of gears with precise specifications. This Maag SH-250 also boasts a maximum face width of 26 inches and can handle a substantial maximum table load of 33,000 pounds, ensuring stability during operation. The ram stroke ranges from a minimum of 2.75 inches to a maximum of 27 inches, providing the adaptability needed for various gear sizes. The diameter of the work table bore is 16.5 inches with a bore length of 47.2 inches, further enhancing its operational efficiency.

With a footprint of 235 inches by 169 inches and a weight of 84,000 pounds, this machine is built to last and perform under demanding conditions. At Superior Machine Tools, we understand the value of quality equipment like the Maag SH-250. If you're looking to sell your used CNC machinery, we offer competitive prices and a seamless selling experience. Contact us today to discuss your Maag SH-250 and get a fair offer!
