Sell your Mazak INTEGREX 200 IVS 2010 today.
Mazak INTEGREX 200 IVS Specifications
| # Axis | 5 |
|---|---|
| 2nd Spindle Bore | 2.99" |
| 2nd Spindle Chuck | 8" |
| 2nd Spindle HP | 30 |
| 2nd Spindle RPM | 5,000 RPM |
| 12 Position Lower Turret | Yes |
| A Axis Travel | 225 Degrees |
| A Axis Rapid Traverse | Not specified |
| Accuracy and Precision | Not specified |
| Air Requirements | Not specified |
| Approximate Dimensions | Not specified |
| Approximate Machine Height | Not specified |
| Approximate Machine Weight | Not specified |
| ATC Capacity | 40 ATC |
| ATC Magazine Capacity | 40 ATC |
| Automatic Tool Changer Capacity | Not specified |
| Axes | Not specified |
| Axis Rapid Rates | Not specified |
| Axis Travels | X: 22.8", Z: 41.14", Y: 6.33", B: 225 Degrees |
| Axis X | 22.8" |
| Axis Y | 6.33" |
| Axis Z | 41.14" |
| B Axis Coupling | 5 Degree |
| B Axis Head Indexing | 0.0001 Deg |
| B Axis Travel | 225 Degrees |
| B Axis Milling Spindle Speed | 12,000 RPM |
| B Axis Spindle Speeds | Not specified |
| C Axis Travel | 0.0001" |
| Control Type | CNC (MAZATROL MATRIX) |
| Maximum Cutting Diameter | 26" |
| Maximum Cutting Length | 41.14" |
| Maximum Tool Diameter | 3.54"/4.92" |
| Maximum Tool Length | 11.8" |
| Tool Change Time | Not specified |
| Tool Holder Type | Not specified |
| Weight Capacity | Not specified |
| Workpiece Weight Capacity | Not specified |
| Workpiece Size | Not specified |
| Spindle Speed Range | Not specified |
| Spindle Motor Power | 30 HP AC |
| Tool Positions | Not specified |
| Rapid Traverse Rate | Not specified |
| Feed Rate | Not specified |
| Cutting Speed | Not specified |
| Number of Tools | Not specified |
| Tool Storage Capacity | 40 ATC |
| Chip Removal System | Yes |
| Coolant System | Not specified |
| Drive System Type | Not specified |
| Control System Type | CNC (MAZATROL MATRIX) |
| Software Compatibility | Not specified |
| Other | Main Spindle Bore/Max Bar Capacity: 2.99/2.4, Tail Stock/Sub Spindle: Sub Spindle, W-Axis Travel Sub Spindle: 41.1", Main Spindle Chuck Size: 8", Main Spindle Chuck Type: Hydraulic, Main Spindle Bore Diameter: 2", Main Spindle Maximum Bar Work: 2.4", Main Spindle Speed: -4 RPM, Sub Spindle/2nd Spindle Chuck Size: 8, Sub Spindle/2nd Spindle Bore Size: 2.99/2.4, Sub Spindle/2nd Spindle Chuck Type: Hydraulic, Sub Spindle/2nd Spindle Speed: 5,000 RPM, Sub Spindle/2nd Spindle Horsepower: 30, Turret Rotary Tool Spindle Speed 1, 2: 12,000, Turret Rotary Tool Horsepower 1, 2: 20, B-Axis Head Indexing: 0°, B Axis Rotary Tool Spindle Speed: 12,000 RPM, B-Axis Rotary Tool Spindle Horsepower: 20 HP, Chip Conveyor: Yes, Milling Spindle Synchronous Tapping: Yes, Tool Eye Automatic Front Spindle: Yes, Tool Eye Automatic Second Spindle: Yes, Tool Eye Measurement Upper Turret: Yes, Tool Eye Measurement Lower Turret: Yes, Coolant Thru Milling Head: Yes, High Pressure Coolant System (PSI): 213, SPECIFICATIONS: MAX. SWING 26.5", MAXIMUM CUTTING LENGTH 41.14", MAX MACHINING DIA 26", AXIS TRAVEL X - AXIS 22.8", AXIS TRAVEL Z - AXIS 41.14", AXIS TRAVEL Y - AXIS 6.33", AXIS TRAVEL B - AXIS 225 DEGREES, AXIS TRAVEL C - AXIS 0.0001 INCREMENTS, AXIS TRAVEL W - AXIS 0.001 INCREMENTS, SPINDLE BORE 2.99", MAX BAR CAPACITY 2.4", SPINDLE NOSE A2-6, SPINDLE SPEEDS 5000 RPM, MAIN SPINDLE HORSEPOWER 30 HP AC, SECOND SPINDLE HORSEPOWER 30 HP AC, SECOND SPINDLE RPM 5000, SECOND SPINDLE INDEXING 0.0001 INCREMENTS, ROTARY TOOL SPINDLE SPEED 12,000 RPM, ROTARY TOOL MOTOR 20 HP, MAX TOOL DIA. (ADJ.) 3.54"/4.92", MAX TOOL LENGTH 11.8", MAXIMUM TOOL WEIGHT 22 LBS., Z - AXIS THRUST 3124 FT/LBS. |
| Other | ImperialMetric, Tail Stock/Sub Spindle: Sub Spindle. |
Do you have a Mazak INTEGREX 200 IVS to sell?
We are actively seeking a 2010 MAZAK INTEGREX 200 IVS CNC Multi-Tasking Machine. This sophisticated piece of equipment is ideal for shops that require versatility and precision in their machining processes. With a maximum swing of 26.5 inches and a maximum turning diameter of 26 inches, the INTEGREX 200 IVS is designed to handle a variety of complex tasks, making it a valuable asset in any manufacturing environment. The machine features a main spindle bore of 2.99 inches, allowing for a maximum bar capacity of 2.4 inches, which is essential for efficient production. Equipped with a robust 30-horsepower main spindle and a sub-spindle that also offers 30 horsepower, this model ensures powerful performance across a range of applications.
The impressive 5,000 RPM sub-spindle speed enhances productivity, while the 12,000 RPM rotary tool spindle speed provides the precision needed for intricate machining tasks. The automatic tool changer (ATC) capacity of 40 tools allows for quick transitions between jobs, helping to minimize downtime in busy shops. The INTEGREX 200 IVS also boasts significant travel capabilities with an X-axis travel of 22.8 inches, Z-axis travel of 41.14 inches, and a Y-axis travel of 6.33 inches. This level of movement, combined with a B-axis travel of 225 degrees and C-axis indexing at .0001 increments, enables the machine to perform a wide range of operations without the need for constant repositioning. Sellers often part with valuable machines like the INTEGREX 200 IVS for various reasons, including upgrading to newer technology, downsizing operations, or even plant closures.
If you're considering selling, now is the perfect time to take advantage of the strong demand for high-quality used CNC machines. At Superior Machine Tools, we understand the intricacies of the selling process and are dedicated to making it as seamless as possible for you. We buy machines nationwide and offer fast payments, ensuring that you receive a fair value for your equipment. Plus, we handle all logistics, so you don't have to worry about transportation or setup. If you're ready to sell your 2010 MAZAK INTEGREX 200 IVS, contact us today to discuss how we can assist you in this process.
Frequently Asked Questions
What types of machinery and equipment do you purchase?
MTE buys a wide range of used and surplus machinery, including CNC machines, metalworking and fabrication equipment, industrial robots, inspection and testing systems, and material handling assets from industries such as metals manufacturing, oil and gas, automotive, and mining.
How does MTE assess the value of my surplus equipment?
Our team conducts a thorough review using current market data, equipment specifications, age, and condition. We provide fair market valuations given your specific situation to ensure you receive maximum value for your assets.
What is the process for selling my excess machinery to MTE?
We make it simple: contact us with asset details, and our specialists will review and coordinate an inspection if needed. After finalizing terms, we handle all logistics, removal, and payment for a smooth and efficient transaction.
How quickly can MTE complete the purchase and removal of my surplus equipment?
MTE prioritizes safe and efficient equipment removal, adhering to your company's specific requirements and timeframes. We coordinate all logistics to ensure the process is carried out safely and efficiently, minimizing risks and protecting both personnel and equipment.
What documentation is required to sell my used machinery?
We typically request detailed equipment information, such as make, model, year, and maintenance records, along with proof of ownership. Our team will guide you through all necessary paperwork to ensure a secure and transparent transaction.
Where is MTE located, and do you offer services outside Michigan?
While MTE is proudly based in Michigan, our services extend across the entire United States and internationally. No matter where your surplus machinery or equipment is located, our team has the experience and logistics capabilities to manage evaluations, purchases, and removals efficiently.
Is MTE an equipment broker?
No. Our business model is based on purchasing equipment outright — MTE does not act as a broker nor do we buy on consignment. We buy machinery and assets upfront, providing immediate payment and a straightforward transaction.
“Selling my CNC machine with MTE was seamless. The team guided me through every step and offered a fair price quickly.”
Michael Rodriguez
Plant Operations Manager
Have one to sell?
MTE is the direct buyer. Quote in 24-48 hours, free pickup, pay on collection.
