Sell your Mazak INTEGREX-100IIIST 2005 today.
Mazak INTEGREX-100IIIST Specifications
| # Axis | 5 |
|---|---|
| 2nd Spindle Bore | 2.4" |
| 2nd Spindle Chuck | Collet |
| 2nd Spindle HP | 15 HP |
| 2nd Spindle RPM | 6000 RPM |
| 5 Axis Machining | Not Available |
| 12 Position Lower Turret | Not Available |
| A Axis Travel | Not Available |
| A Axis Rapid Traverse | Not Available |
| Accuracy and Precision | Not Available |
| Air Requirements | Not Available |
| Approximate Dimensions | Not Available |
| Approximate Machine Height | Not Available |
| Approximate Machine Weight | 18,078 LBS |
| ATC Capacity | 40 ATC |
| ATC Magazine Capacity | Not Available |
| Automatic Tool Changer Capacity | Not Available |
| Axes | Not Available |
| Axis Rapid Rates | Not Available |
| Axis Travels | Not Available |
| Axis X | 16.14" |
| Axis Y | 5.51" |
| Axis Z | 31.69" |
| B Axis Coupling | Not Available |
| B Axis Head Indexing | 225 DEGREE |
| B Axis Travel | Not Available |
| B Axis Milling Spindle Speed | 12,000 RPM |
| B Axis Spindle Speeds | Not Available |
| C Axis Travel | Not Available |
| Control Type | Not Available |
| Maximum Cutting Diameter | Not Available |
| Maximum Cutting Length | Not Available |
| Maximum Tool Diameter | 3.54" |
| Maximum Tool Length | 7.87" |
| Tool Change Time | Not Available |
| Tool Holder Type | Not Available |
| Weight Capacity | Not Available |
| Workpiece Weight Capacity | Not Available |
| Workpiece Size | Not Available |
| Spindle Speed Range | Not Available |
| Spindle Motor Power | Not Available |
| Tool Positions | 9 |
| Rapid Traverse Rate | Not Available |
| Feed Rate | Not Available |
| Cutting Speed | Not Available |
| Number of Tools | Not Available |
| Tool Storage Capacity | Not Available |
| Chip Removal System | Not Available |
| Coolant System | Not Available |
| Drive System Type | Not Available |
| Control System Type | Not Available |
| Software Compatibility | Not Available |
| Other | Distance Between Centers: 0 |
| Distance Between Spindles | 29.65" |
| Chuck Size 1 | Collet |
| Chuck Size 2 | Collet |
| Spindle Nose 1 | A2 - 5 |
| Spindle Nose 2 | A2 - 4 |
| Spindle Bore Diameter 1 | 2.4" |
| Spindle Speeds 1 | 6000 RPM |
| Spindle Horsepower 1 | 15 HP |
| Spindle Horsepower 2 | 15 HP |
| Bar Capacity 1 | 2.0" |
| Spindle Speeds 2 | 6000 RPM |
| B Axis Milling Spindle Taper | KM |
| B Axis Milling Spindle Horse Power | 7.5 HP |
| C Axis Indexing 1 | .0001 Degree |
| C Axis Indexing 2 | .001 Degree |
| W Axis Travel Sub Spindle | 31.30" |
| Rapid Traverse Rates X1 | 1181 IPM |
| Rapid Traverse Rates X2 | 1181 IPM |
| Rapid Traverse Rates Y1 | 1024 IPM |
| Rapid Traverse Rates Z1 | 1299 IPM |
| Turret Tool Positions 1 | 9 |
| Tailstock Quill Diameter | 0 |
| Tailstock Taper | 0 |
| Tailstock Quill Travel | 0 |
| Tailstock Travel | 0 |
| Turret Rotary Tool Speeds 1 | 0 |
| Turret Rotary Tool Horse Power 1 | 0 |
Do you have a Mazak INTEGREX-100IIIST to sell?
We are actively seeking a 2005 Mazak INTEGREX-100IIIST CNC Multi-Tasking Machine. This impressive machine boasts a swing over bed of 21.46 inches and a turning diameter that matches, making it an ideal choice for shops that require versatility in their machining capabilities. With a turning length of 29.65 inches and a spindle bore diameter of 2.4 inches, this model is designed to handle a variety of tasks efficiently. The INTEGREX-100IIIST is equipped with a collet chuck and has a bar capacity of 2.0 inches, ensuring that it can accommodate a range of workpieces. The machine features dual spindles that operate at speeds of up to 6000 RPM, providing the power needed for high-performance machining.
With a spindle horsepower of 15 for each spindle, this machine is capable of tackling demanding jobs with ease. The B-axis head indexing of 225 degrees and the B-axis milling spindle speed of 12,000 RPM further enhance its capabilities, allowing for complex machining operations to be performed without the need for multiple setups. In terms of tooling, the INTEGREX-100IIIST is equipped with a 40-tool automatic tool changer, which streamlines the workflow and minimizes downtime. The tool diameter can reach up to 3.54 inches, and the tool length is up to 7.87 inches, accommodating a variety of cutting tools. Additionally, the rapid traverse rates for the X, Y, and Z axes are impressive, with speeds reaching up to 1299 IPM.
Sellers often part with their machines for various reasons, including upgrading to newer technology, downsizing operations, or even plant closures. If you find yourself in one of these situations, consider selling your Mazak INTEGREX-100IIIST to us. We buy machines nationwide and offer fast payments, ensuring a smooth transaction from start to finish. Our team handles all logistics, so you can focus on your next steps without added stress. Contact us today to learn more about how we can help you sell your machinery with ease.
