Sell your Mazak HQR 100MSY 2015 today.
Mazak HQR 100MSY Specifications
| # Max Turning Diameter | 11.625" |
|---|---|
| Max Tool Diameter | 2" |
| Main Spindle Chuck Size | 6" |
| Main Spindle Bore Diameter | 2.4" |
| Main Spindle Speed | 6,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 15 HP/10 HP |
| 2Nd Spindle Chuck Size | 2.4" |
| 2Nd Spindle Speed | 6,000 RPM |
| 2Nd Spindle Horse Power | 15 HP/10 HP |
| Number Of Turrets | 2 |
| # Tool Positions | 12 |
| B Axis Rotary Tool Spindle Speed | 6,000 RPM |
| B-Axis Rotary Tool Spindle Horsepower | 7.5 HP |
| Chip Conveyor | Yes |
| High Pressure Coolant System (PSI) | 213 |
| Workpiece Unloader & Conveyor | Yes |
| Multi Tap Transformer | Yes |
| Control | CNC (MAZATROL MATRIX CONTROL) |
| Approx Dimensions Lxwxh | 138.19" x 103.98" x 98.31 |
| Approx Machine Weight | 27,778 lbs |
| Approx Weight | 27,778 lbs |
| Other | Maximum Swing: 12.6" |
| Distance Between Spindles | 24.375" |
| X-Axis Travel | 6.875"/4.3125" |
| Z-Axis Travel | 20.375"/22.75" |
| Y-Axis Travel | 4" [±2"]/2.75" [+0.75" –2"] |
| C-Axis Indexing | 0.0001° increments |
| W-Axis Travel Sub Spindle | 24.5 in |
| Main Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Bore Size | 2.4" |
| Sub Spindle/2nd Spindle Chuck Type | Collet |
| Number of Turret Positions | 12 |
| Turret Type | 12-Position Drum Turret (VDI) |
| Turning Tool Shank | 3/4" |
| Boring Bar Shank Diameter | 1-1/4" |
| Turret Indexing Time | 0.2 S / 1 STEP |
| Milling Capacity | (Ø0.63"), ENDMILL |
| Main Spindle (30 Min. Rating) | 11 KW (15 HP) |
| Main Spindle (Cont. Rating) | 7.5 KW (10 HP) |
| Second Spindle (30 Min. Rating) | 11 KW (15 HP) |
| Rotary Tool Spindle (10 Min. Rating) | 5.5 KW (7.5 HP) |
| Height | 95" |
| Floor Space Requirement | 112.68" x 90.16" |
| Machine Weight | 19930 lbs. |
Do you have a Mazak HQR 100MSY to sell?
We are actively seeking a 2015 MAZAK HQR 100MSY Multi Axis CNC Lathe. This sophisticated machine is renowned for its twin-spindle, twin-turret configuration, allowing for high-volume throughput and exceptional part processing capabilities. Equipped with a maximum swing of 12.6 inches and a maximum turning diameter of 11.625 inches, the HQR 100MSY excels in machining complex parts from raw material to finished products in a single setup. With a main spindle speed of 6,000 RPM and a robust horsepower rating of 15 HP, this lathe is designed for precision and efficiency. The MAZAK HQR 100MSY features a sub-spindle that operates at the same impressive speed and power, providing versatility and flexibility in production. The machine's X-axis travel reaches up to 6.875 inches, while the Z-axis offers a generous travel of 20.375 inches, ensuring that it can handle a wide variety of workpieces.
Additionally, the Y-axis travel allows for enhanced machining capabilities, accommodating parts that require intricate detailing. This model is also equipped with a high-pressure coolant system, ensuring optimal performance and longevity of the tooling. With a chip conveyor and a workpiece unloader included, the HQR 100MSY is designed for seamless operation in busy manufacturing environments. Its CNC (MAZATROL MATRIX CONTROL) provides intuitive programming options, making it user-friendly for operators of all skill levels. Sellers often part with machines like the MAZAK HQR 100MSY due to various reasons, including upgrading to newer technology, downsizing their operations, or closing facilities. Regardless of the reason, we understand that selling your machine can be a significant decision.
That's where we come in — at Superior Machine Tools, we strive to make the selling process as smooth as possible. We buy nationwide, offering fast payments and handling all logistics to ensure you have a hassle-free experience. If you own a 2015 MAZAK HQR 100MSY or a similar model and are considering selling, we encourage you to reach out to us. Our team is ready to assist you in evaluating your machine and providing a fair offer. Let us help you turn your equipment into cash while you focus on your next project.
