Sell your Gleason 108 today.
Gleason 108 Specifications
| Accuracy | -12° to 90° |
|---|---|
| Approx Net Weight | 16,000 lbs 7800 kgs |
| Approximate Dimensions | 62 x 85” 1600 x 2200 mm |
| Bore Of Gear/Brake Spindle Large End | 3.29/32” 100 mm |
| Brake Spindle Bore Large End | 3.29/32” 100 mm |
| Brake Spindle Bore Taper Per Ft | 39/64” 15 mm |
| Capacity | 5 to 97 and most numbers up to 175 |
| Center Distance | 5¼” 133 mm |
| Chip Conveyor | - |
| Coarsest Diametral Pitch | DP 4 |
| Control System | - |
| Control Type | - |
| Coolant System | - |
| Cutter Diameter | 3½”, 6” and 7½” 89 mm, 150 mm and 190 mm |
| Cutter Speeds | 74 to 380 22.5 to 115.3 meters per minute |
| Cutter Spindle Diameter | - |
| Depth of taper | 6” 150 mm |
| Diameter Cutters | - |
| Diameter of hole through spindle | 2.7/16” 62 mm |
| Extreme ratio | - |
| Feeds | 3 to 68.6 |
| Main motor | 3 Hp 1800 rpm |
| Maximum gear pitch dia | 8½” 216 mm |
| Maximum Normal Module | - |
| Maximum Spindle Speed | - |
| Net weight | 16,000 lbs 7800 kgs |
| Number of teeth | 5 to 97 and most numbers up to 175 |
| Other | Parts Conveyor |
| Stroke Rate Range | - |
| Taper per foot | 39/64” 15 mm |
| Workhead angle | -12° to 90° |
| WORK SPINDLE | 6” 152 mm |
Do you have a Gleason 108 to sell?
We are actively seeking a Gleason 108 Hypoid Gear Generator. This CNC gear machinery is known for its robust capabilities in producing high-quality gears. With specifications that include a maximum gear pitch diameter of 8½ inches at a 30° spiral angle and the ability to accommodate any practical extreme ratio, the Gleason 108 is a valuable asset for any manufacturing facility. The machine operates efficiently within a diametral pitch of 4, making it suitable for a variety of gear production needs. The workhead angle ranges from -12° to 90°, providing versatility that shops appreciate when it comes to different gear types.
Additionally, this model supports a minimum ratio for pinions to operate with formate gears of 2 to 1, making it a reliable choice for numerous applications. The cutter speeds can range from 74 to 380 feet per minute, allowing for rapid production without sacrificing quality. Furthermore, with a maximum face width of 1¼ inches, it can handle a variety of gear sizes, from 5 to 97 teeth and even most numbers up to 175. The work spindle features a diameter of taper hole at the large end of 3.29/32 inches and a depth of taper of 6 inches, ensuring that it can accommodate various cutters, including those with diameters of 3½, 6, and 7½ inches. The machine's main motor operates at 3 Hp with a hydraulic motor of ¾ Hp, providing the necessary power for demanding tasks.
With a net weight of 16,000 lbs, this machine is built to last, offering stability and reliability in production environments. Sellers often part with their machines for various reasons, such as upgrading to newer models, downsizing operations, or closing facilities altogether. If you're considering selling your Gleason 108 Hypoid Gear Generator, we can assure you a seamless process. We buy nationwide, offer fast payments, and manage all logistics to make your selling experience as smooth as possible. Let us help you turn your used machinery into immediate cash while you focus on your next venture.
