Doosan PUMA 4100 XLMC Specifications
| # Maximum Swing | 31.1" |
|---|---|
| # Max Turning Diameter | 21.7" |
| # Main Spindle Bore/Max Bar Capacity | 7.1"/ 6.5" |
| # Maximum Swing Over Cross Slide | 22" |
| # Maximum Cutting Length | 120.7" |
| # X-Axis Travel | 14.3" |
| # Z-Axis Travel | 122.7" |
| # C-Axis Indexing | 0.001 Deg. |
| # Main Spindle Chuck Size | 21" |
| # Main Spindle Chuck Type | Hydraulic |
| # Main Spindle Bore Diameter | 7.1" |
| # Main Spindle Maximum Bar Work | 6.5" |
| # Main Spindle Speed | 1,500 RPM |
| # Main Spindle Horsepower (CONT. /30 MINS) | 50 |
| # Turret Rotary Tool Spindle Speed 1 | 4000 |
| # Chip Conveyor | Yes |
| # Tool Eye Automatic Front Spindle | Yes |
| # Control | CNC (FANUC 0i-TF) |
| # Dimensions | 263" x 90” x 90” |
| # Weight | 26,600 LBS |
| # Spindle Nose | A1-15 |
| # Spindle Torque | 2432 FT-LBS |
| # Chuck Work Weight | 4,409 LBS |
| # Shaft Work Weight | 7,936 LBS |
| # OD Tool Size | 1” x 1” |
| # Maximum Boring Bar Size | 2.4” |
| # Turret Indexing Time | 0.25 SEC |
| # Tailstock Quill Dia. | 4.7” |
| # Tailstock Stroke | 4.7” |
| # Tailstock Bore Taper | MT#6 |
| # Tailstock Travel | 120.7” |
| # Electrical Power | 380V / 3 Ph / 60 Hz ; 94 AMP ; 55 KVA |
Do you have a Doosan PUMA 4100 XLMC to sell?
We are actively seeking a 2023 DOOSAN PUMA 4100 XLMC Multi Axis CNC Lathe. This powerful machine is equipped with a robust main spindle capable of reaching speeds up to 1,500 RPM, making it ideal for high-performance machining tasks. With a maximum swing of 31.1 inches and a turning diameter of 21.7 inches, the PUMA 4100 XLMC allows for significant versatility in handling various workpieces, including larger components that require precision and efficiency. The main spindle features a hydraulic chuck with a diameter of 21 inches, ensuring a secure grip on your materials, while the maximum bar capacity of 6.5 inches offers the ability to work with substantial stock. Additionally, the CNC control system, powered by FANUC 0i-TF, provides intuitive operation and advanced programming capabilities that enhance productivity.
The machine's dimensions of 263 inches by 90 inches by 90 inches and a weight of 26,600 pounds indicate a solid build designed for durability and stability during operations. Equipped with a 12-position turret and a maximum cutting length of 120.7 inches, this lathe is perfect for complex machining tasks, allowing for rapid tool changes and seamless transitions between operations. The turret indexing time of just 0.25 seconds showcases its efficiency, making it a valuable asset for any busy shop. Moreover, the inclusion of a chip conveyor simplifies cleanup and maintenance, enabling operators to focus on production. Sellers often part with machines like the DOOSAN PUMA 4100 XLMC for various reasons, including upgrading to newer technology, downsizing their operations, or due to plant closures.
Whatever your reason, we understand the importance of a smooth and efficient selling process. We buy machines nationwide, ensuring fast payments and handling all logistics, so you can concentrate on your next steps without the hassle. If you're ready to sell your 2023 DOOSAN PUMA 4100 XLMC or any other CNC equipment, we are here to help. Our team is committed to providing a fair evaluation and a straightforward selling experience. Contact us today to learn more about how we can assist you in selling your machine quickly and effectively.
Frequently Asked Questions
What types of machinery and equipment do you purchase?
MTE buys a wide range of used and surplus machinery, including CNC machines, metalworking and fabrication equipment, industrial robots, inspection and testing systems, and material handling assets from industries such as metals manufacturing, oil and gas, automotive, and mining.
How does MTE assess the value of my surplus equipment?
Our team conducts a thorough review using current market data, equipment specifications, age, and condition. We provide fair market valuations given your specific situation to ensure you receive maximum value for your assets.
What is the process for selling my excess machinery to MTE?
We make it simple: contact us with asset details, and our specialists will review and coordinate an inspection if needed. After finalizing terms, we handle all logistics, removal, and payment for a smooth and efficient transaction.
How quickly can MTE complete the purchase and removal of my surplus equipment?
MTE prioritizes safe and efficient equipment removal, adhering to your company's specific requirements and timeframes. We coordinate all logistics to ensure the process is carried out safely and efficiently, minimizing risks and protecting both personnel and equipment.
What documentation is required to sell my used machinery?
We typically request detailed equipment information, such as make, model, year, and maintenance records, along with proof of ownership. Our team will guide you through all necessary paperwork to ensure a secure and transparent transaction.
Where is MTE located, and do you offer services outside Michigan?
While MTE is proudly based in Michigan, our services extend across the entire United States and internationally. No matter where your surplus machinery or equipment is located, our team has the experience and logistics capabilities to manage evaluations, purchases, and removals efficiently.
Is MTE an equipment broker?
No. Our business model is based on purchasing equipment outright — MTE does not act as a broker nor do we buy on consignment. We buy machinery and assets upfront, providing immediate payment and a straightforward transaction.
