Sell your DMG MORI MT-1500SZ today.
DMG MORI MT-1500SZ Specifications
| # Axis | 5 |
|---|---|
| 2nd Spindle Bore | 2.99″ |
| 2nd Spindle RPM | 35-5000 RPM |
| 2nd Spindle Power | 22 kW |
| 5 Axis Machining | Yes |
| 12 Position Lower Turret | Yes |
| A Axis Travel | 360° |
| A Axis Rapid Traverse | Not specified |
| Accuracy and Precision | Not specified |
| Air Requirements | 71 PSI Overall |
| Approximate Dimensions | 192″ x 99″ x 110″ |
| Approximate Machine Weight | 23,500 lbs |
| ATC Capacity | 40 |
| ATC Magazine Capacity | Not specified |
| Axes | X, Z, Y, W, B, C |
| Axis Rapid Rates | X: 1417 IPM, Z: 1417 IPM, Y: 1351 IPM, B: 1181 IPM |
| Axis Travels | X1: 22.24″, X2: 7.36″, Z1: 41.3″, Z2: 41.3″, Y: 6.7″, W: 41.34″ |
| B Axis Travel | 240° |
| B Axis Spindle Speeds | Not specified |
| C Axis Travel | 360° (0.001°) |
| Control Type | Not specified |
| Maximum Cutting Diameter | Not specified |
| Maximum Cutting Length | 40.15″ |
| Maximum Tool Diameter | Not specified |
| Maximum Tool Length | Not specified |
| Tool Change Time | Not specified |
| Tool Holder Type | CAPTO-C6, BMT-55P |
| Weight Capacity | 1322 lbs |
| Workpiece Weight Capacity | Not specified |
| Workpiece Size | Not specified |
| Spindle Speed Range | 35-5000 RPM, 15-12000 RPM |
| Spindle Motor Power | 22 kW, 18.5 kW |
| Tool Positions | 40 |
| Rapid Traverse Rate | Not specified |
| Feed Rate | Not specified |
| Cutting Speed | Not specified |
| Number of Tools | Not specified |
| Tool Storage Capacity | Not specified |
| Chip Removal System | Not specified |
| Coolant System | Not specified |
| Drive System Type | Not specified |
| Control System Type | Not specified |
| Software Compatibility | Not specified |
| Other | Max Bar Capacity Main Spindle: 2.625″, Max Bar Capacity Sub Spindle: 2.55″, Max Weight on Main & Sub Spindle: 1322 lbs, Max Distance Between Main & Sub Spindle: 52.50″, Max Swing Upper Turret: 29.5″, Max Swing with Y Axis: 19.70″, Max Swing over Cross Slide: 23.6″, Max Turning Diameter Upper Turret: 21.25″, Max Turning Diameter Lower Turret: 11.89″, Max Turning Length: 40.15″, Main Spindle Bore: 2.99″, Sub Spindle Bore: 2.99″, Main Spindle Nose: A2-6, Sub Spindle Nose: A2-6, Main Spindle Speed: 35-5000 RPM, Sub Spindle Speed: 35-5000 RPM, Main Spindle Power: 22 kW, Sub Spindle Power: 22 kW, Milling Head: Single Station Pendulum Head with 40 ATC, Tool Type: CAPTO-C6, 40 Taper, Spindle 5°, Index Time: 0.5 Sec, Lower Turret Capacity: 12 Live Stations Tool, Turret Index Time: 0.2 Second OD, Tool Size: 1.00″ ID, 1.50″ Live, Tool Speed: 5000 RPM, General Power: 87 kVA, 220V / 3-Phase, High Overall Dimensions: 210″ x 99″ x 110″ High with Chip Conveyor. |
Do you have a DMG MORI MT-1500SZ to sell?
We are actively seeking a MORI SEIKI MT-1500SZ CNC Multi-Tasking Machine. This sophisticated machine is designed for precision and efficiency, making it an excellent addition to any manufacturing or machining operation. With a maximum turning diameter of 21.25 inches for the upper turret and 11.89 inches for the lower turret, this machine is capable of handling various tasks with ease. The MT-1500SZ features a maximum swing over the upper turret of 29.5 inches and a maximum swing with Y-axis of 19.70 inches, allowing for versatile machining capabilities. Additionally, it offers a maximum turning length of 40.15 inches, ensuring that it can accommodate a wide range of workpieces. The machine boasts impressive specifications, including a maximum bar capacity of 2.625 inches for the main spindle and 2.55 inches for the sub-spindle, along with a maximum weight capacity of 1322 lbs on both spindles.
The distance between the main and sub-spindle is 52.50 inches, providing ample space for complex operations. The travels are equally impressive, featuring X-axis travel of 22.24 inches for the upper and 7.36 inches for the lower turret, along with Z-axis travel of 41.3 inches for both turrets. The Y-axis travel is 6.7 inches, and the W-axis travel is 41.34 inches for the sub-spindle. Equipped with a 360° C-axis on both spindles and a B-axis travel of 240°, the MT-1500SZ offers unparalleled flexibility for intricate machining tasks. The rapid traverse rates are noteworthy, with X and Z axes capable of 1417 IPM and Y-axis at 1351 IPM. The main and sub-spindles can achieve speeds from 35 to 5000 RPM, powered by robust 22 kW motors, ensuring high productivity and efficiency.
Sellers often part with machines like the MT-1500SZ for various reasons, including upgrading to newer models, downsizing operations, or closing facilities. If you find yourself in a similar position, we are here to help. At Superior Machine Tools, we buy CNC machines nationwide, offering fast payments and handling all logistics for you. Don't hesitate to reach out to us if you're ready to sell your MORI SEIKI MT-1500SZ or any other machinery. We value your time and aim to make the selling process as seamless as possible.
